B78475-P1562-A2 datasheet, PDF

B78475-P1562-A2: DescriptionDatacom Transformer, ISDN Application(s), 1:1:2:2; 1:1:2:2; CategoryPower management transformer; File Size582KB，8 Pages; ManufacturerTDK Corporation; Websitehttp://www.tdk.com

Download Datasheet Parametric Compare View All

B78475-P1562-A2 Overview

Datacom Transformer, ISDN Application(s), 1:1:2:2; 1:1:2:2

Parameter Name	Attribute value
Maker	TDK Corporation
Reach Compliance Code	unknown
ECCN code	EAR99
application	ISDN
high	15.1 mm
Insulation voltage	2000 V
length	30 mm
Installation features	THROUGH HOLE MOUNTED
Number of functions	1
Maximum operating temperature	70 °C
Minimum operating temperature
method of packing	MAGAZINE
physical size	L30XB11XH15.1 (mm)
Primary inductance	30000 µH
surface mount	NO
Transformer type	DATACOM TRANSFORMER
Turns ratio (Np:Ns)	1:1:2:2; 1:1:2:2
width	11 mm
Base Number Matches	1

Inductive Ferrite

Components

ISDN Transformers

Interface Modules

Data Sheet

	B78475-P1562-A2	B78475-P1565-A2	B78475-P1561-A2	B78475-P1560-A2
Description	Datacom Transformer, ISDN Application(s), 1:1:2:2; 1:1:2:2	Datacom Transformer, ISDN Application(s), 1:1:2:2; 1:1:2:2	Datacom Transformer, ISDN Application(s), 1:1:2.5:2.5; 1:1:2.5:2.5	Datacom Transformer, ISDN Application(s), 1:1:4; 1:1:4
Maker	TDK Corporation	TDK Corporation	TDK Corporation	TDK Corporation
Reach Compliance Code	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99
application	ISDN	ISDN	ISDN	ISDN
high	15.1 mm	15.1 mm	15.1 mm	15.1 mm
Insulation voltage	2000 V	1500 V	1500 V	1500 V
length	30 mm	30 mm	30 mm	30 mm
Installation features	THROUGH HOLE MOUNTED	THROUGH HOLE MOUNTED	THROUGH HOLE MOUNTED	THROUGH HOLE MOUNTED
Number of functions	1	1	1	1
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C
method of packing	MAGAZINE	MAGAZINE	MAGAZINE	MAGAZINE
physical size	L30XB11XH15.1 (mm)	L30XB11XH15.1 (mm)	L30XB11XH15.1 (mm)	L30XB11XH15.1 (mm)
Primary inductance	30000 µH	30000 µH	30000 µH	30000 µH
surface mount	NO	NO	NO	NO
Transformer type	DATACOM TRANSFORMER	DATACOM TRANSFORMER	DATACOM TRANSFORMER	DATACOM TRANSFORMER
Turns ratio (Np:Ns)	1:1:2:2; 1:1:2:2	1:1:2:2; 1:1:2:2	1:1:2.5:2.5; 1:1:2.5:2.5	1:1:4; 1:1:4
width	11 mm	11 mm	11 mm	11 mm
Base Number Matches	1	1	1	1
