CD54FCT244M datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> CD54FCT244M

CD54FCT244M: DescriptionFCT SERIES, DUAL 4-BIT DRIVER, TRUE OUTPUT, PDSO20; Categorylogic logic; File Size853KB，6 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

CD54FCT244M Overview

FCT SERIES, DUAL 4-BIT DRIVER, TRUE OUTPUT, PDSO20

CD54FCT244M Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
package instruction	,
Reach Compliance Code	unknown
Other features	TYPICAL VOLP = 1V AT VCC = 5V,TA = 25 DEGREE C
series	FCT
JESD-30 code	R-PDSO-G20
JESD-609 code	e0
Logic integrated circuit type	BUS DRIVER
Number of digits	4
Number of functions	2
Number of ports	2
Number of terminals	20
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output characteristics	3-STATE
Output polarity	TRUE
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
propagation delay (tpd)	7 ns
Certification status	COMMERCIAL
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	BICMOS
Temperature level	MILITARY
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All
