MGDS-25-H-F/T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> MGDS-25-H-F/T

MGDS-25-H-F/T: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 25W, Hybrid, ROHS COMPLIANT, METAL PACKAGE-8; CategoryPower/power management The power supply circuit; File Size556KB，14 Pages; ManufacturerGAIA Converter Inc; Websitehttps://gaia-converter.com; Environmental Compliance

Download Datasheet Parametric View All

MGDS-25-H-F/T Overview

DC-DC Regulated Power Supply Module, 1 Output, 25W, Hybrid, ROHS COMPLIANT, METAL PACKAGE-8

MGDS-25-H-F/T Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	GAIA Converter Inc
Parts packaging code	MODULE
package instruction	ROHS COMPLIANT, METAL PACKAGE-8
Contacts	8
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	36 V
Minimum input voltage	9 V
Nominal input voltage	20 V
JESD-30 code	S-MDMA-P8
JESD-609 code	e3
length	50.8 mm
Maximum load regulation	2.5%
Number of functions	1
Output times	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Maximum output current	1.65 A
Maximum output voltage	15.3 V
Minimum output voltage	14.7 V
Nominal output voltage	15 V
Package body material	METAL
Encapsulate equivalent code	MODULE,8LEAD,1.8
Package shape	SQUARE
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	12.9 mm
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal form	PIN/PEG
Terminal pitch	5.08 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	25 W
Fine-tuning/adjustable output	NO
width	50.8 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Hi-Rel DC/DC CONVERTER

MGDM-25 : 25W POWER

Hi-Rel

Grade

Single, Bi & Triple Outputs

Metallic Case - 1 500 VDC Isolation

• 28Vdc input compliant with MIL-STD-704 D/E

• Nominal power up to 25 W without derating

• Wide temperature range : -40°C/+105°C case

• High efficiency up to 87%

• Soft start

• Galvanic isolation 1.500 VDC

• Integrated LC EMI filter

• Permanent short circuit protection

• No optocoupler for high reliability

• RoHS or Leaded process option

1-General

The MGDM-25 series is a full family of high per-

formance DC/DC power modules designed for

aerospace, military and high-end industrial ap-

plications. These modules use a frequency fixed

swiching technic at 250KHz providing excellent

reliability, low noise characteristics and high

power density. Standard models are available

with nominal input voltage of 28 volts in a vol-

tage range of 9-36, 16-40 volts. The series

include single, bi and triple output voltage

choices of 3,3, 5, 12, 15 volts.

No external heatsink is required for the MGDM-

25 series to supply 25W output power over the

case temperature range of -40°C up to 105°C.

All the modules are designed with LC network

filters to minimize reflected input current ripple

and output voltage ripple.

The modules include a soft-start, a permanent

short circuit protection and an output overvoltage

protection to ensure efficient module protec-

tions.

The soft-start allows current limitation and

eliminates inrush current during start-up. The

short circuit protection completely protects the

modules against short-circuits of any duration

by a shut-down and restores to normal when

the overload is removed.

The design has been carried out with surface

mount components and is manufactured in a

fully automated process to guarantee high

quality. Each module is tested and burned in

with a GAIA converter automated test equipment.

The modules are potted with a bi-component

thermal conductive compound and packaged in

a metallic case to ensure the module’s integrity

under high environmental conditions.

2-Product Selection

Single output model

Bi output model

Triple output model

: MGDS - 25 -

: MGDB - 25 -

: MGDT - 25 -

input

output

option

suffix

Input Voltage Range

Permanent

Transient

Output

B : 3,3 VDC

C : 5 VDC or +/-5VDC

E : 12 VDC or +/-12VDC

F : 15 VDC or +/-15VDC

BE : 3,3 VDC and +/-12 VDC

BF : 3,3 VDC and +/-15 VDC

CE : 5 VDC and +/-12 VDC

CF : 5 VDC and +/-15 VDC

Suffix :

nothing : RoHS process

-L : leaded process

(available in N. America)

H : 9-36 VDC

J : 16-40 VDC

* Consult factory

40 VDC/100 ms *

50 VDC/100 ms *

Options :

/M : On/Off function

/T : option for -55°C start up operating temperature

/S : option for screening and serialization

REDEFINING THE SOURCE OF POWER

Gaia Converter FC98-024.01/11 Revision K

For locations, phone, fax, E-Mail see back cover
