JAN1N5420 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> JAN1N5420

JAN1N5420: DescriptionRectifier Diode, 1 Phase, 1 Element, 5A, 600V V(RRM), Silicon,; CategoryDiscrete semiconductor diode; File Size101KB，2 Pages; ManufacturerVOLTAGE MULTIPLIERS INC.; Websitehttp://www.voltagemultipliers.com/

Download Datasheet Parametric View All

JAN1N5420 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	JAN1N5420	-	-	View	Buy Now

JAN1N5420 Overview

Rectifier Diode, 1 Phase, 1 Element, 5A, 600V V(RRM), Silicon,

JAN1N5420 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	VOLTAGE MULTIPLIERS INC.
package instruction	E-LALF-W2
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
application	GENERAL PURPOSE
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.1 V
JESD-30 code	E-LALF-W2
JESD-609 code	e0
Maximum non-repetitive peak forward current	80 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	175 °C
Maximum output current	5 A
Package body material	GLASS
Package shape	ELLIPTICAL
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Guideline	MIL-19500/411
Maximum repetitive peak reverse voltage	600 V
Maximum reverse recovery time	0.4 µs
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

50 V - 600 V Rectifiers

5.0 A Forward Current

150 ns - 400 ns Recovery Time

AXIAL LEADED

HERMETICALLY SEALED

MIL-PRF-19500/411

JAN

JANTX

JANTXV

1N5415 1N5416

1N5417 1N5418

1N5419 1N5420

ELECTRICAL CHARACTERISTICS AND MAXIMUM RATINGS

Part

Working

Number Reverse

Voltage

(Vrwm)

Average

Rectified

Current

(Io)

Reverse

Current

@ Vrwm

(Ir)

Forward

Voltage

1 Cycle Repetitive Reverse

Surge

Recovery

Current

Time

tp=8.3ms

(3)

(Ifsm)

(Ifrm)

(Trr)

25°C

Amps

25°C

Amps

25°C

Thermal

Impedance

Junction

Cap.

@50VDC

@ 1kHZ

(Cj)

25°C

(Vf)

25°C

Volts

Amps

J-L

L=.125 L=.375 L=.500

°C/W

55°C(1) 100°C(2) 25°C 100°C

Volts

1N5415

1N5416

1N5417

1N5418

1N5419

1N5420

Amps

µA

100

200

400

500

600

5.00

2.00

1.0

1.5

9.0

150

250

400

(1)TL=55°C L=0.375" (2)TL=100°C L=0.375" (3)If=0.5A, Ir=1.0A, Irr=0.25A • Op.Temp.= -65°C to +175°C Stg.Temp.= -65°C to +200°C

.180(4.57)

.115(2.92)

.185(4.7)

MAX.

1.30(33.02)

.90(22.86)

.042(1.07)

.037(.939)

Dimensions: In. (mm) • All temperatures are ambient unless otherwise noted. • Data subject to change without notice.

VOLTAGE MULTIPLIERS INC.

8711 W. Roosevelt Ave.

Visalia, CA 93291

TEL

559-651-1402

FAX

559-651-0740

www.voltagemultipliers.com
