Preview

DG202AK-E3: DescriptionIC QUAD 1-CHANNEL, SGL POLE SGL THROW SWITCH, CDIP16, LEAD FREE, CERDIP-16, Multiplexer or Switch; CategoryAnalog mixed-signal IC The signal circuit; File Size143KB，4 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Related ProductsFound6parts with similar functions to DG202AK-E3

Download Datasheet Parametric Compare View All

DG202AK-E3 Overview

IC QUAD 1-CHANNEL, SGL POLE SGL THROW SWITCH, CDIP16, LEAD FREE, CERDIP-16, Multiplexer or Switch

DG202AK-E3 Parametric

Parameter Name	Attribute value
Parts packaging code	DIP
package instruction	DIP, DIP16,.3
Contacts	16
Reach Compliance Code	unknow
Analog Integrated Circuits - Other Types	SPST
JESD-30 code	R-CDIP-T16
JESD-609 code	e0
length	19.305 mm
Nominal Negative Supply Voltage (Vsup)	-15 V
normal position	NC
Number of channels	1
Number of functions	4
Number of terminals	16
Nominal off-state isolation	70 dB
Maximum on-state resistance (Ron)	175 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
output	SEPARATE OUTPUT
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DIP
Encapsulate equivalent code	DIP16,.3
Package shape	RECTANGULAR
Package form	IN-LINE
power supply	+-15 V
Certification status	Not Qualified
Maximum seat height	5.08 mm
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	450 ns
Maximum connection time	600 ns
switch	BREAK-BEFORE-MAKE
technology	CMOS
Temperature level	MILITARY
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	7.62 mm
Base Number Matches	1

Preview

Download Datasheet

View All

DG202AK-E3 Related Products

	DG202AK-E3	DG528AK-E3	DG271AK-E3
Description	IC QUAD 1-CHANNEL, SGL POLE SGL THROW SWITCH, CDIP16, LEAD FREE, CERDIP-16, Multiplexer or Switch	IC 8-CHANNEL, SGL ENDED MULTIPLEXER, CDIP18, LEAD FREE, CERDIP-18, Multiplexer or Switch	IC QUAD 1-CHANNEL, SGL POLE SGL THROW SWITCH, CDIP16, LEAD FREE, CERDIP-16, Multiplexer or Switch
Parts packaging code	DIP	DIP	DIP
package instruction	DIP, DIP16,.3	DIP, DIP18,.3	DIP,
Contacts	16	18	16
Reach Compliance Code	unknow	unknown	unknown
Analog Integrated Circuits - Other Types	SPST	SINGLE-ENDED MULTIPLEXER	SPST
JESD-30 code	R-CDIP-T16	R-CDIP-T18	R-CDIP-T16
length	19.305 mm	22.605 mm	19.305 mm
Nominal Negative Supply Voltage (Vsup)	-15 V	-15 V	-15 V
Number of channels	1	8	1
Number of functions	4	1	4
Number of terminals	16	18	16
Nominal off-state isolation	70 dB	68 dB	85 dB
Maximum on-state resistance (Ron)	175 Ω	400 Ω	50 Ω
Maximum operating temperature	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DIP	DIP	DIP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	IN-LINE
Certification status	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	5.08 mm	5.08 mm	5.08 mm
Nominal supply voltage (Vsup)	15 V	15 V	15 V
surface mount	NO	NO	NO
Maximum disconnect time	450 ns	1000 ns	65 ns
Maximum connection time	600 ns	1500 ns	65 ns
technology	CMOS	CMOS	CMOS
Temperature level	MILITARY	MILITARY	MILITARY
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL
width	7.62 mm	7.62 mm	7.62 mm
Encapsulate equivalent code	DIP16,.3	DIP18,.3	-
power supply	+-15 V	+-15 V	-
switch	BREAK-BEFORE-MAKE	BREAK-BEFORE-MAKE	-
Maker	-	Vishay	Vishay
Peak Reflow Temperature (Celsius)	-	NOT SPECIFIED	NOT SPECIFIED
Maximum time at peak reflow temperature	-	NOT SPECIFIED	NOT SPECIFIED
