SM Crystal for NFC, Smartcard etc
Specifications
GSX-213
Parameters
Frequency range:
26.0 ~ 60.0MHz
Calibration tolerance:
±10ppm
±15ppm
±30ppm
Other values (±7.5 ~ ±100ppm)
±10ppm
±15ppm
±20ppm
±30ppm
Other values (±5.0 ~ ±100ppm)
Product
GSX-213
M
N
A
S
specify
F
1
P
3
specify
1
P
2
3
specify
1
2
3
specify
Option
Codes
Temperature stability:
1.65
±0.07
1.25
±0.07
+0.03
0.32
-0.02
ACTUAL SIZE
SOLDER PAD LAYOUT
0.40
0.20
Operating temperature range:
-10 to +60°C
-20 to +70°C
-30 to +80°C
Other values
Storage temperature range:
-40 to +85°C
Circuit condition:
8pF
9pF
10pF
Series resonant
Other values
Fundamental
1
4
0.50
(typ)
2
3
0.30
(typ)
0.60
0.60
0.70
PAD
1
2
3
4
CONNECTION
Crystal
Ground & lid
Crystal
Not connected
0.70
Oscillation mode:
Scale 6:1
Features
Equivalent series resistance:
200Ω max @ 26.0MHz
150Ω max @ 37.4MHz
100Ω max @ 38.4MHz
100Ω max @ 40.0MHz
Ageing:
±1ppm max first year
100μW max
Ultra-miniature for maximum space saving
Ideal for NFC, Smartcard, wireless & mobile
Metal lid can be grounded to minimise EMI
Seam sealed for excellent long-term stability
Test drive level:
Soldering condition:
260°C, 10 sec x2 max
Standard.
Optional - Please specify required code(s) when ordering
Ordering Information
Part No, or product name + option codes + frequency
eg:
GSX-213/111NF 26.0MHz
10/10/10/9-F
GSX-213/1P3AF 40.0MHz
10/15/30/10-F
Option code X (eg GSX-213/X) denotes a custom specification.
±10ppm temperature stability may not be available over -30+80°C.
Check with our sales office before ordering.
Tel:
+44 1460 256 100
21 Sep 2011
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
Product Information
Construction
GSX-213
Ceramic body with gold-plated pads
Metal lid, seam sealed
Composition
RoHS
2002/95/EC
This product is lead-free, and is fully compliant with
the RoHS directive 2002/95/EC
Pb
LeadFree
Packaging & Handling
Production quantities supplied on T & R, 3k pcs per reel.
Small quantities may be supplied on tape (no reel), or in bulk.
Soldering Profile
°C
10s max
Marking
FREQUENCY
T DC
Marking type: Laser
DC = Date code
260
200
Tape & Reel Specification
2.0 2.0
±0.02
0.2
1.0Ø 1.5Ø
1.75
100
5°C/s max
5°C/s max
5°
±0.05
3.5
MARK
1.85
8.0
±0.3
Preheat
140~160°C
0
60~90s max
Heat
> 200°C
50~60s max
Slow
cooldown
Time
Maximum solder resistance: 260°C x 10 secs x 2.
0.45
1.45
FEED
8.4
-0.4
1.5
120°
2.50
±0.2
+0.6
±0.3
20.5Ø
178Ø
±1.0
13Ø
60Ø
±1.0
Not to scale. Dimensional tolerances ±0.1mm unless otherwise stated
Tel:
+44 1460 256 100
21 Sep 2011
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
