3-557101-7 Product Details
Live Product Chat
Product Photo
1.27 [.050] Series I, HD, FH and J Connectors
5 of 6 EU R oHS/ELV C om pliant
(
Find R oHS C om pliant
Alte rnate s
/
Sta te m e nt of C om pliance
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3-557101-7
T E I nternal N umber: 3 - 5 5 7 1 0 1 - 7
Product Highlights:
l
C onnector
l
Receptacle
l
Number of Positions = 160
l
1.27 mm C enterline
l
Standard Profile
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Superseded
Search for Replacement Parts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
C HAMP Interconnection System
(PDF, English)
l
C HAMP .050 SERIES C ONNEC TORS
(PDF, English)
l
PERSONAL SYSTEMS PRODUC TS
(PDF, English)
Product Specifications:
l
C onnector, C HAMP, 050, Board-To-Board, Vertical and ...
(PDF, English)
l
C HAMP* 050 Series I .025 Inch C enterline C onnector
(PDF, English)
Application Specifications:
l
C HAMP .050 Series I Board-To-Board C onnectors
(PDF, English)
l
C HAMP .050 Series I C onnectors for 0.64 mm (.025 In....
(PDF, English)
Instruction Sheets:
l
Base Assembly Universal Arbor Tool 768338-4
(PDF, English)
l
C onnector-Specific Kit 679177-2 for C HAMP .050 Serie...
(PDF, English)
l
Pneumatic Auto-C ycle Unit 91112-3
(PDF, English)
l
Manual Arbor Frame Assembly 91085-2
(PDF, English)
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Gender
= Receptacle
l
Number of Positions
= 160
l
Profile
= Standard
l
PC B Mount Style = Through Hole
l
PC B Retention Feature = Yes
l
PC B Mount Angle
= Right Angle
l
C onnector Type
= Series I
l
PC B Mount Polarization
= Without
l
C olor = Black
l
Used For = Board To Board Applications
l
Sealed Bottom = Without
l
Product Series = Series I
Mechanical Attachment:
l
Boardlock Material = Brass
l
Boardlock Plating = Tin-Lead
Termination Related Features:
l
Termination Post Length (mm [in])
= 3.10 [0.122]
l
Solder Tail C ontact Plating = Tin-Lead
Body Related Features:
l
C enterline (mm [in])
= 1.27 [0.050]
l
PC B Retention Method
= Boardlock(s)
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Temperature Rating
= High
l
Housing Material = Liquid C rystal Polymer (LC P)
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Operation/Application:
l
Application
= Standard
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
