ATTENUATORS
TNC, up to 6 GHz, 100 Watts
SPECIFICATIONS:
Models: XT100W-XX, XT100W-XXF, XT100W-XXM
Electrical:
Frequency Range
Standard Freq. Values
Standard dB Values
Attenuation Accuracy
1 - 6 dB
10 - 40 dB
VSWR (Max.)
Input Power
Reverse Power
Peak Power
Impedance
Operating Temp Range
DC - 6.0 GHz
1.5, 3 & 6 GHz
3, 6, 10, 20, 30 & 40* dB
1.5 - 2.5 GHz
2.5 - 6 GHz
±0.50 dB
±0.75 dB
±1.0 dB
±1.5 dB
1.25:1
1.35:1
100 Watts Avg.
o
Custom Mtg. hole Config.
may be Added to this
Surface
DC - 1.5 GHz
±0.50 dB
±0.75 dB
1.15:1
Derated Linearly to 20 Watts @ +125 C
20 Watts Max.
2 kW Max.
(5uSec Pulse, .05% Duty Cycle)
50 Ohms
-54°C to +125°C
Mechanical:
TNC Connectors **
Mates with MIL-STD-348
3.46±.02
[87.88±0.51]
SQUARE
Passivated Stainless Steel
Gold Plated Beryllium Copper
Anodized Aluminum
Conductors
Housing
END VIEW
TYPICAL
Units must be Mounted in such a way as to
Allow for Free Air Flow Around fins to Assure
Performance
*40 dB Units are only available up to 4 GHz
** TNC Connectors are 18 GHz Mode Free.
Note: Units are Unidirectional, Input Connector will be Indicated on Unit
Model Number:
XT100W-XX
Male/Female Connectors
Length: 6.53 ±.05 [165.9 ±1.3]
Pictured
INPUT
Model Number:
XT100W-XXF
Female/Female Connectors
Length: 6.62 ±.05 [168.1 ±1.3]
6.53 ±.05
[165.9 ±1.3]
1.75
[44.5]
.23 [5.8]
Model Number:
XT100W-XXM
Male/Male Connectors
Length: 6.43 ±.05 [163.3 ±1.3]
M4x0.7 TAP
x .50 [12.7] DP.
8-32UNC-2B TAP
x .50 [12.7] DP.
HOW TO ORDER:
Model Number:
XT100W-XXY
Connector Configuration
= Male/Female
F = Fem/Fem
M = Male/Male
dB Value
Ordering Examples:
Model Number:
1T100W-1
DC - 1.5 GHz, 1 dB; TNC - Male/Fem
Model Number:
3T100W-3F
DC - 3 GHz, 3 dB; TNC - Fem/Fem
Model Number:
6T100W-20M
DC - 6 GHz, 20 dB; TNC - Male/Male
XT100W-ATT: REV M
Freq. Range
1 = DC - 1.5 GHz
3 = DC - 3 GHz
6 = DC - 6 GHz
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Aeroflex / Inmet, Inc.
• 300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex-inmetcorp.com • sales@aeroflex-inmetcorp.com
