Series 700 Elevator Strip-Line
Sockets with Bifurcated Contacts
FEATURES:
• For elevated mounting of LCDs and other odd-centered or high pin count
components.
• Any height from .360 to 2.000 [9.14 to 50.80].
•Optional spacer available for mounting on .300 [7.62], .600 [15.24], .900
[22.86], 1.100 [27.94], and 1.300 [33.02] centers. Consult factory for other
sizes.
SPECIFICATIONS:
• Body is black UL 94-V0 Glass-filled 4/6 Nylon.
• Pin is Grade A Phosphor Bronze per QQ-B-750.
• Optional spacer is FR-406, .032 [.81] thick.
• Pin plating is
11
= 10μ [.25μm] min. Gold per MIL-G-45204 over 50μ [1.27μm] min.
Nickel per SAE-AMS-QQ-N-290.
10
= 200μ” min. Matte Tin per ASTM B545-97 over 50μ” min Nickel per
SAE-AMS-QQ-N-290.
10TL
= 200μ” min. 90/10 Tin/Lead per MIL-T-10727 Type 1 over 50μ” min
Note: Aries specializes in custom design and production. In addition to the
Nickel per SAE-AMS-QQ-N-290.
standard products shown on this page, special materials, platings, sizes, and
• Current rating=1.5 Amp.
configurations can be furnished, depending on quantities. Aries reserves the
right to change product specifications without notice.
• Operating temperature= -67°F to 221°F [-55°C to 105°C] Tin &
Tin/Lead plating,
= -67°F to 257°F [-55°C to 125°C] Gold.
• Insertion Force=110 grams/pin average; Withdrawal
XX-7XXXX-1XXX
Force=75 grams/pin average.
Plating:
No. of pins
• Accepts flat leads up to .014 x .020 wide [.36-.51], round leads up to .020
0 = Tin
(see table)
[.51] in diameter.
0TL = Tin/Lead
• Socket accepts lead lengths from seating plane
Series
1 = Gold
.080-.160 [2.03-4.06].
Elevated height:
MOUNTING CONSIDERATIONS:
.360-2.000 [9.14-50.80] Solder tail pin
• Suggested PCB hole size=.045 ± .002 [.1.14 ± .05] dia.
ORDERING INFORMATION
“A”=(NO. OF PINS X .100 [2.54]) + .050 [1.27]
“B”=(NO. OF PINS PER ROW - 1) X .100 [2.54]
CONTACT DETAIL
INCHES
[
MILLIMETERS
]
A
LL DIMENSIONS
:
All tolerances ± .005 [.13]
unless otherwise specified
ORDERING INFORMATION
(for spacer bar)
0500-X.XXX
Series
PINS MAY BE
SUPPLIED WITH
CUT ENDS
Other sizes
available.
Consult factory.
No. of Pins
20
25
30
34
40
No. of Grooves
2
2
2
3
2
Center-to-center
mounting desired
(“C” dimension)
SPACER
BAR
EUROPE
TEL: +44 870 240 0249
FAX: +44 871 919 6033
europe@arieselec.com
http://www.arieselec.com • info@arieselec.com
NORTH AMERICA
Frenchtown, NJ USA
TEL:(908) 996-6841
FAX:(908) 996-3891
abc
12010
REV.E
