P150 SERIES
ENGINEERING DATA SHEET
SOLID STATE POWER CONTROLLER
28 VDC, 1PNO-WITH CURRENT OR VOLTAGE
STATUS OUTPUT
UP TO 30 AMP RATING
DESCRIPTION
The P150 Series of Solid State Power Controllers (SSPC) is rated
from 2 to 30 Amperes. These LEACH SSPC's feature reliable,
trouble free switching together with real short circuit protection.
Employing a power FET output stage, and built using thick film
technology, they offer low on state resistance and low on state
voltage drop. They react to fault condition and can shutdown within
microseconds, if required. Two status signals, derived from the load
current value or voltage and from the device gate, are reported via
optical isolators. Designed to operate in 28 VDC systems, these
devices do not require derating for any load type. They are
hermetically sealed, in a metal package.
SIZE: 69.6 x 34 x 9.65 mm
FEATURES
.
Fast acting
.
Built-in overload and short circuit protection
.
Load current or voltage status
BLOCK DIAGRAM
.
FET Gate status or trip status
.
Very low voltage drop
.
No derating up to 105° C
.
Trip free
.
Fully isolated bias, control and status
.
No derating for non-resistive loads
.
Exceeds MIL-P-81653C requirements
.
Very low voltage drop output stage
Tel: (33) 3 87 97 31 01 Tel: (852) 2 191 3830
Fax: (33) 3 87 97 96 86 Fax: (852) 2 389 5803
Fax: (01) 714-670-1145
Data sheets are for initial product selection and comparison. Contact Leach International prior to choosing a component.
Featuring
LEACH
©
power and control solutions
Tel: (01) 714-736-7599
www.leachintl.com
-9-
EUROPE
AMERICAS
6900 Orangethorpe Ave. 2 Rue Goethe
57430 Sarralbe
P.O. Box 5032
Buena Park, CA 90622 USAFrance
ASIA
Room 501, 5/F, The Centre Mark
287 - 299 Queen's Road Central
Hong Kong
Date of issue: 4/10
Page 1 of 6
ELECTRICAL CHARACTERISTICS (CURRENT STATUS)
Typical values are at 25 ± 5° C
INPUT
Parameter
BIAS On Voltage
BIAS On current
BIAS Off current
CONTROL voltage on
CONTROL voltage off
CONTROL current on
CONTROL current off
Transients (BIAS input)
Notes:
1. BIAS voltage must be a step function.
2. No reverse polarity protection.
3. BIAS voltage is 5.0 V.
Symbol
V
IHB
I
IHB
I
ILB
V
IHC
V
ILC
I
IHC
I
ILC
V
TB
2.4
-0.8
0.8
50
-10
+50
P150 SERIES
DEVICE WITH CURRENT STATUS
Min.
4.5
Typ.
Max.
5.5
10
1
Unit
V
mA
mA
V
V
µA
µA
V
4
5
6
Notes
1,2
3
3
4. Control voltage at 2.4 vdc.
5. Control voltage at 0.4 vdc.
6. Max. Duration 50 ms, Duty Cycle 1%, Repetition Rate 1 Hz.
OUTPUT
Parameter
Load current
On state voltage drop
Off state line voltage
Gate high voltage
Gate high current
Gate low voltage
Gate low current
Load pick up
Load drop out
Leakage current
Transient voltage
Spikes
Trip current
Isolation voltage
Insulation resistance
Symbol
I
L
V
LD
V
L
V
OHS
I
OHS
V
OLS
I
OLS
I
SON
I
SOFF
I
LL
V
T
V
S
I
TR
V
ISO
R
INS
100
-600
110
130
5
1
+50
+600
145
750
1000
2.4
50
0.8
0.2
15
Min.
0
Typ.
Max.
100
200
32
Unit
%I rated
mV
V
V
µA
V
mA
%I rated
%I rated
mA
V
V
%I rated
VRMS
MΩ
8
4
5
6
7
Note
1
2
3
Notes:
1. Load current is subject to thermal derating.
2. At load current I
L
=100% rated value.
3. Reverse polarity is not blocked and may damage the SSPC.
4. At V
L
=28V, Case temperature = 105° C.
5. Duration 12.5 ms max. per MIl-STD-704D.
6. Duration 10 µs max. per Mil-STD-704D.
7. See Trip Characteristics.
8. 500 Vdc, ± 10%
Date of issue: 4/10
- 10 -
Page 2 of 6
TRIP CHARACTERISTIC
P150 SERIES
TIMING DIAGRAM (CURRENT STATUS)
TIMING
Parameter
CONTROL to GATE delay
Turn on delay
Load current rise time
Turn on to LOAD delay
CONTROL to GATE
Turn off delay
Load current fall time
Turn off to LOAD delay
Symbol
t
0
t
1
t
2
t
3
t
4
t
5
t
6
t
7
Typ.
300
150
30
75
150
150
20
400
Max.
1000
200
1000
1000
1000
200
1000
1000
Unit
µs
µs
µs
µs
µs
µs
µs
µs
2
Note
Notes:
1. All timing measurements taken at 10% and 90% points into resistive rated load.
2. Current fall time from trip dependant on overload condition.
Date of issue: 4/10
- 11 -
Page 3 of 6
ELECTRICAL CHARACTERISTICS (VOLTAGE STATUS)
Typical values are at 25 ± 5° C
INPUT
Parameter
Logic supply voltage
CONTROL voltage high
CONTROL voltage low
Transient
Spikes
REQUIREMENTS
28 Vdc initialization spike voltage
During of output spike at 50%
amplitude shall be 100µsec
maximum
Vline = 28 Vdc, Vcontrol = 0
Vdc, Vbias = 0 to 5 Vdc, rated at
<1 msec
I
CC
I
LOAD
V
O
I
L
V
OH
V
OL
I
IH
I
IL
V
ON
IOH=5mA
IOL=1mA
VI=2.4 Vdc
VI=0.4 Vdc
See Timing Diagram (Voltage
Status)
30
2.4
0.4
50
10
70
V
CC
=5.5 Vdc
50
100
200
1
5
P150 SERIES
LIMITS
MIN
4.5
2.0
0.8
MAX
5.5
Vdc
Vdc
Vdc
Vdc
Vdc
2
2
DEVICE WITH VOLTAGE STATUS
Symbol
V
CC
V
IH
V
IL
Pulse width = 12.5 msec max.
per MIL-STD-704D
Pulse width = 10 µsec max. per
MIL-STD-704D
CONDITIONS
-55°C to +105°C (1)
UNIT
NOTES
+50
-600
+600
V
PR
5 Vdc initialization control
3
mA
%I
mV
mA
Vdc
Vdc
µA
µA
%
5,6,7
5
4
Logic supply current
Load current continuous
"ON" state voltage drop
Leakage current
STATUS & TRIP voltage high
STATUS & TRIP voltage low
CONTROL current high
CONTROL current low
Output "ON" sense voltage
Notes:
1. Unless specified otherwise, test conditions shall be at Vcc=5.0
±0.25Vdc and Vline=28±0.5Vdc. The design shall be capable of
meeting all requirements with Vcc=4.5 to 5.5Vdc.
2. The transient and spike requirements apply only to the 28Vdc
power lines.
3. The device output shall remain off when 5V bias is raised from 0
to 5Vdc.
4. Without any load connected to the STATUS or TRIP outputs.
5. At 100% rated current.
6. Rated resistive load; measurements taken between 10% and
90% points.
7. Percent of actual applied Vline.
Date of issue: 4/10
- 12 -
Page 4 of 6
TIMING DIAGRAM (VOLTAGE STATUS)
P150 SERIES
TIMING
Parameter
Turn-on time
Turn-off time
Load voltage rise time
Load voltage fall time
STATUS on delay
STATUS of delay
TRIP on delay
TRIP of delay
CONTROL pulse width for device reset
Symbol
t
on
t
off
t
R
t
F
t
D1
t
D3
t
D2
t
D4
P
R
50
20
Conditions -55°C to +105°c
See Timing Diagram
Min.
Max.
1000
1000
200
200
2000
2000
150
150
Unit
µsec
µsec
µsec
µsec
µsec
µsec
µsec
µsec
msec
Notes
1,3
1,3
1,3
1,3
1
1
2
2
Notes:
1. At 100% rated current.
2. At 250% rated current.
3. Rated resistive load; measurements taken between 10% and 90% points.
Date of issue: 4/10
- 13 -
Page 5 of 6
