T-1 3/4 (5mm) SOLID STATE LAMP
L-53IDLK
HIGH EFFICIENCY RED
Features
!
HIGH INTENSITY.
!
LOW
Description
The High Efficiency Red source color devices are made with
Gallium Arsenide Phosphide on Gallium Phosphide Orange
Light Emitting Diode.
POWER CONSUMPTION.
!
POPULAR T-1 3/4 DIAMETER PACKAGE.
!
GENERAL PURPOSE LEADS.
!
RELIABLE AND RUGGED.
!
LONG LIFE - SOLID STATE RELIABILITY.
!
AVAILABLE ON TAPE AND REEL.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: DSAA4931
APPROVED : J. Lu
REV NO: V.1
CHECKED :
DATE: OCT/26/2001
DRAWN: Z.W.Yan
PAGE: 1 OF 3
Selection Guide
Par t No .
L-53IDLK
Dic e
HIGH EFFICIENCY RED(GaAsP/GaP)
L en s Ty p e
RED DIFFUSED
8
Iv (m c d )
@ 10 m A
Min .
Ty p .
25
V i ew i n g
An g l e
2θ1/2
60 °
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
λ
peak
λ
D
∆λ
1/2
C
V
F
I
R
Par am et er
Peak Wavelength
Dominate Wavelength
D ev i c e
High Efficiency Red
High Efficiency Red
Ty p .
6 27
6 25
45
15
2.0
2.5
10
Max .
Un it s
nm
nm
nm
pF
V
uA
Tes t Co n d it io n s
IF=20mA
IF=20mA
IF=20mA
VF=0V;f=1MHz
IF=20mA
V R = 5V
Spectral Line Halfwidth High Efficiency Red
Capacitance
Forward Voltage
Reverse Current
High Efficiency Red
High Efficiency Red
High Efficiency Red
Absolute Maximum Ratings at T
)
=25°C
°
P ar a m e t e r
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
H i g h E f f i c i e n c y R ed
105
30
16 0
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Un it s
mW
mA
mA
V
SPEC NO: DSAA4931
APPROVED : J. Lu
REV NO: V.1
CHECKED :
DATE: OCT/26/2001
DRAWN: Z.W.Yan
PAGE: 2 OF 3
