With a diameter of just 2 mm, the PointLED is one of
the smallest packages in its class and achieves high
luminous efficacies. Due to its round and flat package,
measuring only 0.775 mm high, it is ideal for
application where space is a sensitive issue.
Mit nur 2 mm Durchmesser gehört die PointLED zu
den kleinsten LED auf dem Markt bei hohen
Effizienzen. Aufgrund ihres runden und flachen
Gehäuses mit nur 0,775 mm Bauhöhe ist sie ideal für
Applikationen mit begrenztem Raum.
•
Package:
white SMT package, colorless clear
resin
•
Technology:
InGaAlP
•
Viewing angle at 50 % I
V
:
120° (Lambertian
Emitter)
•
Color:
yellow (587 nm)
•
Corrosion Robustness:
Improved corrosion
robustness
Features:
•
Gehäusetyp:
weißes SMT Gehäuse, farbloser
klarer Verguss
•
Technologie:
InGaAlP
•
Abstrahlwinkel bei 50 % I
V
:
120° (Lambertscher
Strahler)
•
Farbe:
gelb (587 nm)
•
Korrosionsstabilität:
Verbesserte
Korrosionsstabilität
Besondere Merkmale:
Applications
•
•
•
•
Coupling into Light Guides
Optical Indicator
Backlighting
Automotive Interior Lighting
•
•
•
•
Anwendungen
Einkopplung in Lichtleiter
Optischer Indikator
Hinterleuchtung
Automobilbeleuchtung innen
2013-07-29
1
Version 1.0
Ordering Information
Bestellinformation
Type:
Typ:
Mounting
methode
Montierbarkeit
Luminous
Intensity
1)
page 19
Lichtstärke
1)
Seite 19
LY P47B
Ordering Code
Bestellnummer
I
F
= 30 mA
I
V
[mcd]
LY P47B-T2V1-26-1-F
LY P47B-T2V1-26-1
Note:
top mount
reverse mount
355 ... 900
355 ... 900
Q65110A4727
Q65110A4726
The above Type Numbers represent the order groups which include only a few brightness groups (see page 5). Only one group will be shipped on each
packing unit (there will be no mixing of two groups on each packing unit). E. g. LY P47B-T2V1-26-1 means that only one group T2, U1, U2, V1 will be
shippable for any packing unit. In order to ensure availability, single brightness groups will not be orderable.
In a similar manner for colors where wavelength groups are measured and binned, single wavelength groups will be shipped on any one packing unit.
E. g. LY P47B-T2V1-26-1 means that only one wavelength group 2,3,4,5,6 will be shippable. LY P47B-T2V1-26-1 means that the device will be shipped
within the specified limits as stated on page 5In order to ensure availability, single wavelength groups will not be orderable (see page 5).
In a similar manner for colors where forward voltage groups are measured and binned, single forward voltage groups will be shipped on any packing
unit. E. g. LY P47B-T2V1-26-1 means that only one forward voltage group 3A,3B,4A,4B will be shippable. In order to ensure availability, single forward
voltage groups will not be orderable (see page 5).
Anm.:
Die oben genannten Typbezeichnungen umfassen die bestellbaren Selektionen. Diese bestehen aus wenigen Helligkeitsgruppen (siehe Seite 5). Es
wird nur eine einzige Helligkeitsgruppe pro Verpackungseinheit geliefert. Z. B. LY P47B-T2V1-26-1 bedeutet, dass in einer Verpackungseinheit nur
eine der Helligkeitsgruppen T2, U1, U2, V1 enhalten ist. Um die Liefersicherheit zu gewährleisten, können einzelne Helligkeitsgruppen nicht bestellt
werden.
Gleiches gilt für die Farben, bei denen Wellenlängengruppen gemessen und gruppiert werden. Pro Verpackungseinheit wird nur eine
Wellenlängengruppe geliefert. Z. B. LY P47B-T2V1-26-1 bedeutet, dass in einer Verpackungseinheit nur eine der Wellenlängengruppen 2,3,4,5,6
enthalten ist (siehe Seite 5). LY P47B-T2V1-26-1 bedeutet, dass das Bauteil innerhalb der spezifizierten Grenzen geliefert wird. Um die Liefersicherheit
zu gewährleisten, können einzelne Wellenlängengruppen nicht bestellt werden.
Gleiches gilt für die LEDs, bei denen die Durchlassspannungsgruppen gemessen und gruppiert werden. Pro Verpackungseinheit wird nur eine
Durchlassspannungsgruppe geliefert. Z. B. LY P47B-T2V1-26-1 bedeutet, dass nach Durchlassspannungsgruppen gruppiert wird. In einer
Verpackungseinheit ist nur eine der Durchlassspannungsgruppen 3A,3B,4A,4B enthalten (siehe Seite 5). Um die Liefersicherheit zu gewährleisten,
können einzelne Durchlassspannungsgruppen nicht direkt bestellt werden.
2013-07-29
2
Version 1.0
Maximum Ratings
Grenzwerte
Parameter
Bezeichnung
Operating temperature range
Betriebstemperatur
Storage temperature range
Lagertemperatur
Junction temperature
Sperrschichttemperatur
Forward current
Durchlassstrom
(T
S
= 25 °C)
Surge current
Stoßstrom
(t <= 10
μs,
D = 0.1)
Reverse voltage
2)
page 19
Sperrspannung
2)
Seite 19
(T
S
= 25 °C)
ESD withstand voltage
ESD Festigkeit
(acc. to ANSI/ESDA/JEDEC JS-001 - HBM)
Symbol
Symbol
T
op
T
stg
T
j
I
F
Values
Werte
-40 ... 100
-40 ... 100
125
60
LY P47B
Unit
Einheit
°C
°C
°C
mA
I
FM
100
mA
V
R
12
V
V
ESD
up to 2
kV
2013-07-29
3
Version 1.0
Characteristics
(T
S
= 25 °C; I
F
= 30 mA)
Kennwerte
Parameter
Bezeichnung
Wavelength at peak emission
Wellenlänge d. emittierten Lichtes
Dominant Wavelength
3)
page 19
Dominantwellenlänge
3)
Seite 19
Spectral bandwidth at 50% I
rel max
Spektrale Bandbreite b. 50% I
rel max
Viewing angle at 50 % I
V
Abstrahlwinkel bei 50 % I
V
Forward voltage
4)
page 19
Durchlassspannung
4)
Seite 19
Reverse current
Sperrstrom
(V
R
= 12 V)
Temperature coefficient of
λ
peak
Temperaturkoeffizient von
λ
peak
(-10°C
≤
T
≤
100°C)
Temperature coefficient of
λ
dom
Temperaturkoeffizient von
λ
dom
(-10°C
≤
T
≤
100°C)
Temperature coefficient of V
F
Temperaturkoeffizient von V
F
(-10°C
≤
T
≤
100°C)
Real thermal resistance junction / ambient
5)
page 19
, 6)
page 19
LY P47B
Symbol
Symbol
(typ.)
(min.)
(typ.)
(max.)
(typ.)
(typ.)
(min.)
(typ.)
(max.)
(typ.)
(max.)
(typ.)
λ
peak
λ
dom
λ
dom
λ
dom
Δλ
2ϕ
V
F
V
F
V
F
I
R
I
R
TC
λpeak
Values
Werte
594
580
587
595
15
120
1.80
2.10
2.40
0.01
10
0.13
Unit
Einheit
nm
nm
nm
nm
nm
°
V
V
V
μA
µA
nm/K
(typ.)
TC
λdom
0.1
nm/K
(typ.)
TC
V
-3.70
mV/K
(max.)
R
th JA real
420
K/W
Realer Wärmewiderstand Sperrschicht /
Umgebung
5)
Seite 19
, 6)
Seite 19
6)
page 19
Real thermal resistance junction / solder point
(max.)
R
th JS real
200
K/W
Realer Wärmewiderstand Sperrschicht / Lötpad
6)
Seite 19
Note:
Anm.:
Individual forward voltage groups see next page
Durchlassspannungsgruppen siehe nächste Seite
2013-07-29
4
Version 1.0
Brightness Groups
Helligkeitsgruppen
Group
Gruppe
T2
U1
U2
V1
Note:
Anm.:
LY P47B
Luminous Intensity
1)
page 19
Luminous Intensity
1)
page 19
Luminous Flux
7)
page 19
Lichtstrom
7)
Seite 19
(typ.)
Φ
V
[mlm]
1200
1500
1900
2400
Lichtstärke
355
450
560
710
1)
Seite 19
Lichtstärke
1)
Seite 19
(max.) I
v
[mcd]
450
560
710
900
(min.) I
v
[mcd]
The standard shipping format for serial types includes a grouping of only a few brightness groups. Individual brightness groups cannot be ordered.
Die Standardlieferform von Serientypen beinhaltet eine Sammelgruppe, die aus nur wenigen Helligkeitsgruppen besteht. Einzelne Helligkeitsgruppen
sind nicht bestellbar.
Forward Voltage Groups
4)
page 19
Durchlassspannungsgruppen
4)
Seite 19
Group
Gruppe
3A
3B
4A
4B
(min.) V
F
[V]
1.80
1.95
2.10
2.25
(max.) V
F
[V]
1.95
2.10
2.25
2.40
Dominant Wavelength Groups
3)
page 19
Dominant Wellenlängengruppen
3)
Seite 19
Group
Gruppe
2
3
4
5
6
Note:
Anm.:
yellow
(min.)
λ
dom
[nm]
580
583
586
589
592
(max.)
λ
dom
[nm]
583
586
589
592
595
No packing unit / tape ever contains more than one color group for each selection.
In einer Verpackungseinheit / Gurt ist immer nur eine Gruppe für jede Farbe enthalten.
