533420-4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 533420-4

533420-4: DescriptionCONNECTOR, 105 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, PLUG; CategoryThe connector The connector; File Size115KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

533420-4 Overview

CONNECTOR, 105 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, PLUG

533420-4 Parametric

Parameter Name	Attribute value
Objectid	1420288846
Reach Compliance Code	unknown
YTEOL	0
Body/casing type	PLUG
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD (30) OVER NICKEL
Contact completed and terminated	TIN
Contact point gender	MALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	3
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	105

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Two-Piece C onnector

Product Feature Selector

> Product Details

533420-4 Product Details

Live Product Chat

Product Photo

AMP-HDI (Four Beam) & TBC (Twin Beam) Connectors

Not re vie we d for R oHS C om plia nce

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

533420-4

T E I nternal N umber: 5 3 3 4 2 0 - 4

Product Highlights:

C onnector

Plug

Number of Positions = 105

PC B Mount Style = Through Hole

PC B Mount Angle = Right Angle

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

HDI, ASSEMBLY 3 ROW, RIGHT ANGLE PIN 4.57 [.180] LON...

(PDF, English)

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

AMP-HDI C onnectors

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= C onnector

Gender

= Plug

Number of Positions

= 105

PC B Mount Style

= Through Hole

PC B Mount Angle

= Right Angle

Make First / Break Last

= No

Mating Polarization

= Without

PC B Retention Feature

= No

Termination Related Features:

Termination Post Length (mm [in])

= 4.57 [0.180]

Solder Tail C ontact Plating

= Tin

Body Related Features:

Number of Rows

= 3

C enterline (mm [in])

= 2.54 [0.100]

Contact Related Features:

C ontact Type

= Four-Beam

C ontact Mating Area Plating Material

= Gold (30)

C ontact Base Material = Phosphor Bronze

C ontact Underplating = Nickel

Housing Related Features:

Housing Material

= Polyphenylene Sulfide (PPS)

Housing C olor = Brown

Housing Material Temperature = High

Configuration Related Features:

C enter Guide = Without

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Other:

Brand = AMP

Additional Information:

Product Line Information
