R573823340: DescriptionRF Coaxial Relay, SP3T, Latched, 0.125A (Coil), 28VDC (Coil), 3500mW (Coil), 40000MHz, 5W (RF Input), DC Input, Panel Mount, ROHS COMPLIANT; CategoryMechanical and electronic products relay; File Size235KB，2 Pages; ManufacturerRadiall; Websitehttps://www.radiall.com/

Download Datasheet Parametric View All

R573823340 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	R573823340	-	-	View	Buy Now

R573823340 Overview

RF Coaxial Relay, SP3T, Latched, 0.125A (Coil), 28VDC (Coil), 3500mW (Coil), 40000MHz, 5W (RF Input), DC Input, Panel Mount, ROHS COMPLIANT

R573823340 Parametric

Parameter Name	Attribute value
Maker	Radiall
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Factory Lead Time	5 weeks 5 days
Other features	WITH POSITIVE COMMON AND SUPPRESSION DIODE
body height	55.5 mm
Body length or diameter	57.15 mm
Characteristic impedance	50 Ω
Maximum coil current (DC)	0.125 A
Coil power	3500 mW
Coil resistance	224 Ω
Maximum coil voltage (DC)	28 V
Coil/Input Power Type	DC
Electrical life	2000000 Cycle(s)
Maximum input power	5 W
Maximum insertion loss	1.1 dB
Maximum isolation	50 dB
Manufacturer's serial number	R573823340
Installation features	PANEL MOUNT
Maximum operating frequency	40000 MHz
Minimum operating frequency
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Relay action	LATCHED
Relay function	SP3T
Relay type	RF COAXIAL RELAY
seal	SPLASH PROOF
surface mount	NO
switching time	15 ms
Termination type	CONNECTOR AND SOLDER
voltage standing wave ratio	2.2
Base Number Matches	1

Preview

Download Datasheet

View All

TECHNICAL DATA SHEET

Description :

Options :

SP3T 40GHz SMA 2.9 LATCHING 28V SWITCH

POSITIVE COMMON / SUPP. DIODES

R573823340

Issue 06.02.13

Page 1/2

RF CHARACTERISTICS

Number of ways

Frequency range

Impedance

Frequency (GHz)

VSWR max

Insertion loss max

Isolation min

Average power (*)

0-6

1.30

0.20 dB

70 dB

40 W

6 - 12.4

1.40

0.40 dB

60 dB

30 W

: 0 - 40 GHz

: 50 Ohms

12.4 - 18

1.50

0.50 dB

60 dB

25 W

18 - 26.5

1.70

0.70 dB

55 dB

15 W

26.5 - 40

2.20

1.10 dB

50 dB

ELECTRICAL CHARACTERISTICS

Actuator

Nominal current **

Actuator voltage (Vcc)

Terminals

LATCHING

125 mA / RESET : 375 mA ****

28V (24 to 30V) / POSITIVE COMMON

solder pins (250°C max. / 30 sec.)

MECHANICAL CHARACTERISTICS

Connectors

Life

Switching Time***

Construction

Weight

SMA 2.9 female per MIL-C 39012

2.000.000 cycles per position

< 15 ms

Splashproof

< 220 g

ENVIRONMENTAL CHARACTERISTICS

Operating temperature range

Storage temperature range

: -40°C to +85°C

: -55°C to +85°C

(**

(***

(****

Average power at 25°C per RF Path)

At 25° C ±10%)

Nominal voltage ; 25° C)

Reset : supply voltage time 1sec. max. / duty cycle 10%)
