390217-3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 390217-3

390217-3: DescriptionSIMM/DIMM SOCKET,184 CONTACTS,2; CategoryThe connector The connector; File Size107KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

390217-3 Overview

SIMM/DIMM SOCKET,184 CONTACTS,2

390217-3 Parametric

Parameter Name	Attribute value
Objectid	303466415
Reach Compliance Code	unknown
ECCN code	EAR99
YTEOL	0
Other features	TRAY PACKAGING
Board mount options	COMPLIANT BOARDLOCK
body width	0.301 inch
subject depth	0.906 inch
body length	5.787 inch
Body/casing type	RECEPTACLE
Connector type	CARD EDGE CONNECTOR
Contact to complete cooperation	AU ON NI
Contact completed and terminated	TIN/LEAD OVER NICKEL
Contact material	PHOSPHOR BRONZE
Contact resistance	20 mΩ
Contact style	BELLOWED TYPE
Dielectric withstand voltage	500VAC V
Durability	25 Cycles
Filter function	NO
maximum insertion force	.8618 N
Insulation resistance	1000000 Ω
Insulator color	BLACK
insulator material	POLYAMIDE
Plug contact pitch	0.039 inch
Mixed contacts	NO
Installation option 1	LATCH & EJECT
Installation option 2	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	4
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
PCB contact pattern	STAGGERED
PCB contact row spacing	0.063 mm
Plating thickness	15u inch
polarization key	POLARIZED KEY
Rated current (signal)	0.5 A
Guideline	UL, CSA
Terminal length	0.154 inch
Terminal pitch	2.0066 mm
Termination type	SOLDER
Total number of contacts	184
Evacuation force-minimum value	.3614 N

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Socket/C ard Products

Product Feature Selector

> Product Details

390217-3 Product Details

Live Product Chat

Memory Sockets

Not re vie we d for R oHS C om plia nce

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

390217-3

T E I nternal N umber: 3 9 0 2 1 7 - 3

Product Highlights:

Rambus RIMM

Gold (15) C ontact Mating Area Plating Material

Number of Positions = 184

DRAM Type = Direct RDRAM

DRAM Voltage = 2.5 V

View all Features

Obsolete

C ontact Product Information

C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

RIMM C ONNEC TOR 184 POSITION

(PDF, English)

Catalog Pages/Data Sheets:

PERSONAL SYSTEMS PRODUC TS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

Rambus In-Line Memory Module (RIMM) Sockets

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Rambus RIMM

Number of Positions

= 184

DRAM Type

= Direct RDRAM

PC B Mount Style = Through Hole

Module Orientation

= Vertical

PC B Retention Feature = Yes

Profile = Standard

Mechanical Attachment:

C enter Retention Hole Diameter (mm [in])

= 2.44 [0.096]

Electrical Characteristics:

DRAM Voltage

= 2.5 V

Termination Related Features:

Termination Post Length (mm [in])

= 3.90 [0.153]

Solder Tail C ontact Plating = Tin-Lead over Nickel

Body Related Features:

C enterline (mm [in])

= 1.00 [0.039]

Number of Rows

= Dual

Ejector Type = Locking

Ejector Location

= Both Ends

Number of Bays

= 2

Number of Keys

= 2

PC B Retention Method = Boardlock(s)

Mount Type = Printed C ircuit Board

Contact Related Features:

C ontact Mating Area Plating Material = Gold (15)

C ontact Base Material = Phosphor Bronze

Retention Post Material = Stainless Steel

Housing Related Features:

Housing Material = High Temperature Nylon

Housing C olor = Black

Housing Flammability Rating = UL 94V-0

Configuration Related Features:

Insertion Style

= Direct Insert

Industry Standards:

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Operation/Application:

Application Type = RIMM, SPRIMM

Packaging Related Features:

Packaging Method = Tray

Other:

Brand = AMP

Additional Information:
