GZF3V6C thru GZF91C
New Product
Vishay Semiconductors
formerly General Semiconductor
V
Z
Range
3.6 to 91V
Power Dissipation
800mW
Zener Diodes
DO-219AB (SMF)
Cathode Band
Top View
1.8
±
0.1
1.0
±
0.2
5
°
0.98
±
0.1
5
°
Detail
Z
enlarged
Z
2.8
±
0.1
0.05 - 0.30
ted
ten
Pa
Mounting Pad Layout
1.6
1.2
1.2
0.60
±
0.25
0.00 – 0.10
3.7
±
0.2
Dimensions in millimeters
Mechanical Data
Case:
JEDEC DO-219 Plastic Case
Weight:
approx. 0.01g
Packaging codes/options:
D3/10K per 13” reel (8mm tape), 30K/box
D4/3K per 7” reel (8mm tape), 30K/box
Features
• Silicon Planar Power Zener Diodes.
• Low profile surface-mount package.
Maximum Ratings and Thermal Characteristics
Parameter
Zener Current (see Table “Characteristics”)
Power Dissipation at T
A
= 25°C
Thermal Resistance Junction to Ambient Air
Maximum Junction Temperature
Storage Temperature Range
Note:
(1) FR-4 or FR-5 board with 3 x 3mm solder pad layout
(T
A
= 25°C unless otherwise noted)
Symbol
Value
800
(1)
188
(1)
175
–65 to +175
Unit
P
tot
R
θJA
T
j
T
S
mW
°C/W
°C
°C
Document Number 88353
01-May-02
www.vishay.com
1
GZF3V6C thru GZF91C
Vishay Semiconductors
formerly General Semiconductor
Electrical Characteristics
(T
Marking
Code
W5
W6
W7
W8
W9
WA
WB
WC
WD
WE
WF
WG
WH
WI
WK
WL
WM
WN
WO
WP
WR
WS
WT
WU
WW
WX
WY
WZ
X1
X2
X3
X4
X5
X6
X7
A
= 25°C unless otherwise noted)
Maximum V
F
= 1.2 V at I
F
= 200mA
Zener Voltage
V
Z
(V) @ I
Z
Nom.
Max.
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
3.8
4.1
4.6
5.0
5.4
6.0
6.6
7.2
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
25.6
28.9
32
35
38
41
46
50
54
60
66
72
79
87
96
Differential
Resistance
r
dif
(Ω) @ I
Z
Typ.
Max.
4
4
4
3
3
2
2
1
1
1
2
2
4
4
5
5
6
6
6
6
7
7
8
8
21
21
24
24
25
25
25
25
30
30
60
8
8
7
7
6
4
3
3
2
2
4
4
7
7
10
10
15
15
15
15
15
15
15
15
40
40
45
45
60
60
80
80
100
100
200
Temperature
Coefficient
Test
Current
Reverse Current at
Reverse Voltage
V
R
(V)
1
1
1
1
1
2
2
3
3
3
5
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
α
Z
@ I
Z
(%/°C)
Min.
–0.14
–0.14
–0.12
–0.10
–0.08
–0.04
–0.01
0.00
0.00
0.03
0.03
0.05
0.05
0.05
0.05
0.05
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.07
0.07
0.07
0.07
0.08
0.08
0.08
0.08
0.09
Max.
–0.04
–0.04
–0.02
0.00
–0.20
0.04
0.06
0.07
0.07
0.08
0.08
0.09
0.10
0.10
0.10
0.10
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.12
0.12
0.12
0.12
0.13
0.13
0.13
0.13
0.13
I
ZT
(mA) I
R
(µA)Max
100
100
100
100
100
100
100
100
100
100
50
50
50
50
50
50
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
10
5
100
50
25
10
5
10
5
10
50
10
10
7
4
3
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Type
GZF3V6C
GZF3V9C
GZF4V3C
GZF4V7C
GZF5V1C
GZF5V6C
GZF6V2C
GZF6V8C
GZF7V5C
GZF8V2C
GZF9V1C
GZF10C
GZF11C
GZF12C
GZF13C
GZF15C
GZF16C
GZF18C
GZF20C
GZF22C
GZF24C
GZF27C
GZF30C
GZF33C
GZF36C
GZF39C
GZF43C
GZF47C
GZF51C
GZF56C
GZF62C
GZF68C
GZF75C
GZF82C
GZF91C
www.vishay.com
2
Min.
3.4
3.7
4.0
4.4
4.8
5.2
5.8
6.4
7.0
7.7
8.5
9.4
10.4
11.4
12.4
13.8
15.3
16.8
18.8
20.8
22.8
25.1
28
31
34
37
40
44
48
52
58
64
70
77
85
Document Number 88353
01-May-02
