M5M467400DTP-6 Overview

FAST PAGE MODE 67108864-BIT (16777216-WORD BY 4-BIT) DYNAMIC RAM

M5M467400DTP-6 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Mitsubishi
Parts packaging code	TSOP
package instruction	TSOP2, TSOP32,.46
Contacts	32
Reach Compliance Code	unknow
ECCN code	EAR99
access mode	FAST PAGE
Maximum access time	60 ns
Other features	RAS ONLY/CAS BEFORE RAS/HIDDEN REFRESH
I/O type	COMMON
JESD-30 code	R-PDSO-G32
JESD-609 code	e0
length	20.95 mm
memory density	67108864 bi
Memory IC Type	FAST PAGE DRAM
memory width	4
Number of functions	1
Number of ports	1
Number of terminals	32
word count	16777216 words
character code	16000000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	16MX4
Output characteristics	3-STATE
Package body material	PLASTIC/EPOXY
encapsulated code	TSOP2
Encapsulate equivalent code	TSOP32,.46
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	3.3 V
Certification status	Not Qualified
refresh cycle	8192
Maximum seat height	1.2 mm
self refresh	NO
Maximum standby current	0.0005 A
Maximum slew rate	0.12 mA
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	10.16 mm

Preview

Download Datasheet

View All

(Rev. 1.0)

MITSUBISHI LSIs

M5M467400/465400DJ,DTP -5,-6,-5S,-6S

M5M467800/465800DJ,DTP -5,-6,-5S,-6S

M5M465160DJ,DTP -5,-6,-5S,-6S

FAST PAGE MODE 67108864-BIT (16777216-WORD BY 4-BIT) DYNAMIC RAM

FAST PAGE MODE 67108864-BIT (8388608-WORD BY 8-BIT) DYNAMIC RAM

FAST PAGE MODE 67108864-BIT (4194304-WORD BY 16-BIT) DYNAMIC RAM

PRELIMINARY

DESCRIPTION

The M5M467400/465400DJ,DTP is a 16777216-word by 4-bit, M5M467800/465800DJ,DTP is a 8388608-word by 8-bit, and

M5M465160DJ,DTP is a 4194304-word by 16-bit dynamic RAMs, fabricated with the high performance CMOS process, and are

suitable for large-capacity memory systems with high speed and low power dissipation.

Some of contents are subject to change without notice.

FEATURES

Type name

M5M467400DXX-5,5S

M5M467800DXX-5,5S

M5M467400DXX-6,6S

M5M467800DXX-6,6S

M5M465400DXX-5,5S

M5M465800DXX-5,5S

M5M465400DXX-6,6S

M5M465800DXX-6,6S

Address

Power

RAS

CAS

Cycle

access access access

access

dissipa-

time

tion

time

(max.ns) (max.ns) (max.ns) (max.ns) (min.ns) (typ.mW)

Type name

M5M465160DXX-5,5S

M5M465160DXX-6,6S

Power

Address

RAS

CAS

Cycle

dissipa-

access access access

access

time

tion

time

(max.ns) (max.ns) (max.ns) (max.ns) (min.ns) (typ.mW)

110

300

250

390

325

110

420

390

XX=J,TP

Standard 32 pin SOJ, 32 pin TSOP (M5M467400Dxx/M5M465400Dxx/M5M467800Dxx/M5M465800Dxx)

Standard 50 pin SOJ, 50 pin TSOP (M5M465160Dxx)

Single 3.3

0.3V supply

Low stand-by power dissipation

1.8mW (Max)

LVCMOS input level

Low operating power dissipation

M5M467400Dxx-5,5S / M5M467800Dxx-5,5S

360.0mW (Max)

M5M467400Dxx-6,6S / M5M467800Dxx-6,6S

324.0mW (Max)

M5M465400Dxx-5,5S / M5M465800Dxx-5,5S

468.0mW (Max)

M5M465400Dxx-6,6S / M5M465800Dxx-6,6S

432.0mW (Max)

M5M465160Dxx-5,5S

504.0mW (Max)

M5M465160Dxx-6,6S

468.0mW (Max)

Self refresh capability*

Self refresh current

400µA (Max)

Fast-page mode , Read-modify-write, CAS before RAS refresh, Hidden refresh capabilities

Early-write mode and OE to control output buffer impedance

All inputs, outputs LVTTL compatible and low capacitance

:Applicable to self refresh version(M5M467400/465400/467800/465800/465160DJ,DTP-5S,-6S:option) only

ADDRESS

Part No.

Row Add. Col. Add.

Refresh

Refresh Cycle

Normal

S-version

RAS Only Ref,Normal R/W 8192/64ms 8192/128ms

M5M467400Dxx A0-A12

M5M465400Dxx A0-A11

M5M467800Dxx A0-A12

A0-A10

CBR Ref,Hidden Ref

4096/64ms 4096/128ms

A0-A11

RAS Only Ref,Normal R/W 4096/64ms 4096/128ms

CBR Ref,Hidden Ref

RAS Only Ref,Normal R/W 8192/64ms 8192/128ms

A0-A9

CBR Ref,Hidden Ref

4096/64ms 4096/128ms

M5M465800Dxx A0-A11 A0-A10

RAS Only Ref,Normal R/W 4096/64ms 4096/128ms

CBR Ref,Hidden Ref

M5M465160Dxx A0-A11 A0-A9

RAS Only Ref,Normal R/W

4096/64ms 4096/128ms

CBR Ref,Hidden Ref

APPLICATION

Main memory unit for computers, Microcomputer memory, Refresh memory for CRT

Aug. 1999

MITSUBISHI ELECTRIC
