F-213 SUPPLEMENT (Rev 25NOV13)
(0,635 mm) .025"
6QDP SERIES
6QDP–032–06.0–STR–TTR–2
6QDP–016–06.0–STR–TBR–3–B
HIGH SPEED TWINAX CABLE ASSEMBLIES
SPECIFICATIONS
For complete specifications see
www.samtec.com?6QDP
Cable:
30 AWG
twinax micro ribbon
Signal Routing:
100Ω Differential
Cable Bending Radius:
(11,11 mm) 7/16" min
Plating:
Au over 50µ" (1,27 µm) Ni
Current Rating:
700 mA per pin
(6 adjacent pins powered)
Propagation Delay:
4.67 nsec/meter
Operating Temp Range:
-40°C to +105°C
Skew (pair-to-pair):
<10 ps/ft
Skew (within a pair):
<5 ps/ft
EMI Performance:
FCC Class A
RoHS Compliant:
Yes
Mates with:
QMS-DP, QFS-DP
Increased
Insertion Depth
APPLICATIONS
Differential
Pair routing
30 AWG
twinax ribbon cable
TYPE
NO. OF
PAIRS
WIRE
LENGTH
END
NO. 1
END
NO. 2
WIRING
OPTION
SCREW
OPTION
–“XX.X”
6QDP
APPLICATIONS
(15,11)
.595
= Unshielded
mates with
QMS-DP/QFS-DP
–016,
–032,
–048,
–064
= Wire Length
in Inches
(43,7 mm) 01.7"
minimum
Specify
END
ASSEMBLIES
from chart
–1
= Pin 1 to
Pin 1
Leave
blank for
no Screw
Option
–2
= Pin 1 to
Pin 2
–F
= End No. 1
Processing conditions will
affect mated height.
END TO END
Surface Mount to
Surface Mount
L
(23,88)
.940
–3
= Pin 1 to
Second
Last Pin
–S
= End No. 2
–B
= Both
Ends
ALSO AVAILABLE
(MOV Required)
• Other pin counts
• Other terminations
Contact Samtec.
OAL = Wire Length +
L
Wire Length
±(1,27) .050
–4
SURFACE MOUNT
ASSEMBLY
END 1
064
001
= Pin 1 to
Last Pin
END 2
064
001
Note:
Cable lengths longer than
40.00" (1 meter) are not
supported with S.I. test data.
Note:
Design your High Speed
Cable with Samtec’s High
Speed Cable Solutionator
®
at www.samtec.com/hdr
Note:
This Series is non-standard,
non-returnable.
(7,47)
.294
END NO. 1
(-TTL SHOWN)
END NO. 2
(-STR SHOWN)
–TTR
=Terminal,
Top,
Notch
Right
–TTL
=
Terminal,
Top,
Notch
Left
–TBR
=
Terminal,
Bottom,
Notch
Right
–TBL
=
Terminal,
Bottom,
Notch
Left
–STR
=
Socket, Top,
001
Notch
Right
–STL
=
Socket, Top,
064
Notch
Left
–SBR
=
Socket,
Bottom,
Notch
Right
001
–SBL
=
Socket,
Bottom,
Notch
Left
064
064
001
001
064
064
001
WIRING REQUIREMENTS
WIRING
END OPTIONS
OPTION
1 or 2
TTR, TBL, STL, SBR to
TTR, TBL, STL, SBR
or
TTL, TBR, STR, SBL to
TTL, TBR, STR, SBL
TTL, TBR, STR, SBL to
TTR, TBL, STL, SBR
or
TTR, TBL, STL, SBR to
TTL, TBR, STR, SBL
001
064
3 or 4
WWW.SAMTEC.COM
