BA51W12ST datasheet, PDF - EEWORLD Datasheet

BA51W12ST: DescriptionFixed Positive Standard Regulator, 2 Output, 9V1, 5V2, BIPolar, PSFM5, TO-220FP, 5 PIN; CategoryPower/power management The power supply circuit; File Size118KB，10 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BA51W12ST Overview

Fixed Positive Standard Regulator, 2 Output, 9V1, 5V2, BIPolar, PSFM5, TO-220FP, 5 PIN

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	TO-220FP
package instruction	TO-220FP, 5 PIN
Contacts	3
Reach Compliance Code	compliant
ECCN code	EAR99
Adjustability	FIXED
Nominal dropback voltage 1	0.3 V
Maximum absolute input voltage	35 V
Maximum input voltage	25 V
Minimum input voltage	10 V
JESD-30 code	R-PSFM-T5
JESD-609 code	e3/e2
Maximum grid adjustment rate	0.1%
Maximum load regulation	0.15%
Number of functions	1
Output times	2
Number of terminals	5
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current 1	1 A
Maximum output current 2	0.5 A
Maximum output voltage 1	9.45 V
Minimum output voltage 1	8.55 V
Nominal output voltage 1	9 V
Nominal output voltage 2	5 V
Package body material	PLASTIC/EPOXY
Encapsulate equivalent code	SIP5,.1,67TB
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Regulator type	FIXED POSITIVE MULTIPLE OUTPUT STANDARD REGULATOR
surface mount	NO
technology	BIPOLAR
Terminal surface	TIN/TIN COPPER
Terminal form	THROUGH-HOLE
Terminal pitch	1.7 mm
Terminal location	SINGLE
Maximum time at peak reflow temperature	10
Maximum voltage tolerance	5%
Base Number Matches	1

Regulator ICs

Dual output voltage regulator

with power saving

BA51W12ST

The BA51W12ST is a general-purpose, low saturation power supply with two outputs : 9V, 1A and 5V, 500mA. The IC

is available in a compact TO220FP-5 package. The outputs can be turned off during the power saving state with the

built-in switch. Also built in the IC is an overcurrent protection circuit, an overvoltage protection circuit, and a thermal

shutdown circuit.

FApplications

Car audio systems, VCRs, facsimiles, air conditioners, and other household and industrial equipment

FFeatures

1) Minimum I / O voltage differential is 0.5V or less.

2) Built-in protection circuits against overcurrent, over-

voltage, and overheat.

FAbsolute

maximum ratings (Ta = 25_C)

3) Available in a compact TO220FP-5 package (pins

are bendable).

4) Zero power saving current. (Typ.)

FRecommended

operating conditions (Ta = 25_C)

117
