The patent-pending CMQ23496 is an indoor broadband four-port MIMO omnidirectional ceiling mount antenna.
It is designed to provide pattern coverage that is optimized for indoor requirements at 2300-2700 MHz and
4900-5950 MHz frequency bands. The individual antenna elements are designed to radiate a pattern that has been
specifically shaped to provide optimal radiation within a coverage zone.
▪
▪
▪
▪
▪
▪
▪
▪
Low profile, aesthetically-neutral housing
Mounts directly and easily to ceiling tile
Optimized performance using Laird proprietary RF optimization tools
Excellent flame retardancy rating
Four radiating elements optimized for indoor applications
Provides MIMO/MUMIMO capabilities for multiband 802.11n and
802.11ac applications
Optional antenna mounting kits are available to accommodate a variety
of installation requirements
Attractive, compact design and form factor ideal for indoor solution
applications
2300-2400
<1.4:1
<2:1
4.4
4.9
< -17
< -19
< -20
< -20
< -20
< -19
< -19
4.5
5.6
< -18
< -19
< -21
< -21
< -20
< -20
< -21
10
50
2400-2500
4
▪
▪
▪
▪
▪
▪
WLAN – 802.11n and 802.11ac
Building operators – Offices and
meeting rooms
Hospitality – Hotels and casinos
Transportation – Airport, bus, and train
terminals
Retail – Stores and indoor malls
Education – Libraries and museums
Operating Frequency (MHz)
Number of Ports
VSWR – Avg
VSWR – Max
Gain – Typ (dBi)
Gain – Max (dBi)
Isolation Port – Max (dB)
Port 1 > Port 2 – Typ (dB)
Port 1 > Port 3 – Typ (dB)
Port 1 > Port 4 – Typ (dB)
Port 2 > Port 3 – Typ (dB)
Port 2 > Port 4 – Typ (dB)
Port 3 > Port 4 – Typ (dB)
Max Power - Ambient 25°C (W)
Nominal Impedance (Ohms)
Polarization
Horizontal Plane 3 dB Beamwidth Port 1
2500-2700
<1.8:1
<2:1
4.5
5.6
< -18
< -19
< -22
< -22
< -21
< -20
< -21
4900-5950
5.4
6.3
< -24
< -26
< -24
< -25
< -25
< -25
< -26
Linear Vertical
Omnidirectional
Dimensions – diameter x height – mm (inches)
Weight – kg (lbs.)
Cable Type
Radome Material
Mounting
178 x 32 (7.0 x 1.26)
1.18 (2.60)
Ultralink, Plenum-rated
PC/ABS, UL94-V0, UV Stable, White
Ceiling mount (drywall or tile flush)
Operating Temperature – °C (°F)
Storage Temperature – °C (°F)
Material Substance Compliance
-30 to +70°C (-22 to +158°F)
-40 to +85°C (-40 to +185°F)
RoHS
CMQ23496-75RSM
CMQ23496-91NF
CMQ23496-91RTN
4x – 75 mm
4x – 91 mm
4x – 91 mm
4x – RSMA Male
4x – Type N Female
4x – RTNC Male
sales@lairdconnect.com
support@lairdconnect.com
www.lairdconnect.com
Laird warrants to the original end user customer of its products that its products are free from defects in material and workmanship. Subject to conditions and limitations Laird will, at its
option, either repair or replace any part of its products that prove defective because of improper workmanship or materials. This limited warranty is in force for the useful lifetime of the
original end product into which the Laird product is installed. Useful lifetime of the original end product may vary but is not to exceed five (5) years from the original date of the end product
purchase.
Any information furnished by Laird Inc. and its agents is believed to be accurate and reliable. All specifications are subject to change without notice. Responsibility for the use and application
of Laird materials rests with the end user, since Laird and its agents cannot be aware of all potential uses. Laird makes no warranties as to the fitness,
merchantability or suitability of any Laird materials or products for any specific or general uses. Laird shall not be liable for incidental or consequential damages of any kind. All Laird products
are sold pursuant to the Laird Terms and Conditions of sale in effect from time to time, a copy of which will be furnished upon request.
© Copyright 2019 Laird Inc. All Rights Reserved. Laird, Laird Technologies, the Laird Logo, and other marks are trademarks or registered trademarks of Laird Inc. or an affiliate company
thereof. Other product or service names may be the property of third parties. Nothing herein provides a license under any Laird or any third party intellectual property rights.
