M54HCT14
M74HCT14
HEX SCHMITT INVERTER
.
.
.
.
.
.
.
HIGH SPEED
t
PD
= 16 ns (TYP.) AT V
CC
= 5 V
LOW POWER DISSIPATION
I
CC
= 1
µA
(MAX.) AT T
A
= 25
°C
HIGH NOISE IMMUNITY
V
H
= 0.7 V (TYP.) AT V
CC
= 5 V
OUTPUT DRIVE CAPABILITY
10 LSTTL LOADS
SYMMETRICAL OUTPUT IMPEDANCE
IOH
= I
OL
= 4 mA (MIN.)
BALANCED PROPAGATION DELAYS
t
PLH
= t
PHL
PIN AND FUNCTION COMPATIBLE WITH
54/74LS14
B1R
(Plastic Package)
F1R
(Ceramic Package)
M1R
(Micro Package)
C1R
(Chip Carrier)
DESCRIPTION
The M54/74HCT14 is a high speed CMOS HEX
SCHMITT INVERTER fabricated in silicon gate
C
2
MOS technology. It has the same high speed per-
formance of LSTTL combined with true CMOS low
power consumption. Pin configuration and function
are the same as those of the HCT04 but all inputs
have 0.7 V hysteresis level.This together with its
schmitt trigger function allows it to be used on line
receivers with slow rise/fall input signals. This inte-
grated circuit has input and output characteristics
that are fully compatible with 54/74 LSTTL logic
families. M54/74HCT devices are designed to di-
rectly interface HSC
2
MOS systems with TTL and
NMOS components. They are also plug in replace-
ments for LSTTL devices giving a reduction of
power consumption.All inputs are equipped with pro-
ORDER CODES :
M54HCT14F1R
M74HCT14M1R
M74HCT14B1R
M74HCT14C1R
PIN CONNECTIONS
(top view)
INPUT AND OUTPUT EQUIVALENT CIRCUIT
NC =
No Internal
Connection
October 1993
1/9
M54/M74HCT14
TRUTH TABLE
A
L
H
Y
H
L
IEC LOGIC SYMBOL
PIN DESCRIPTION
PIN No
1, 3, 5, 9,
11, 13
2, 4, 6, 8,
10,12
7
14
SYMBOL
1A to 6A
1Y to 6Y
GND
V
CC
NAME AND FUNCTION
Data Inputs
Data Outputs
Ground (0V)
Positive Supply Voltage
LOGIC DIAGRAM/WAVEFORM
ABSOLUTE MAXIMUM RATINGS
Symbol
V
CC
V
I
V
O
I
IK
I
OK
I
CC
I
O
or I
GND
P
D
T
stg
T
L
Supply Voltage
DC Input Voltage
DC Output Voltage
DC Input Diode Current
DC Output Diode Current
DC Output Source Sink Current Per Output Pin
DC V
CC
or Ground Current
Power Dissipation
Storage Temperature
Lead Temperature (10 sec)
Parameter
Value
-0.5 to +7
-0.5 to V
CC
+ 0.5
-0.5 to V
CC
+ 0.5
±
20
±
20
±
25
±
50
500 (*)
-65 to +150
300
Unit
V
V
V
mA
mA
mA
mA
mW
o
o
C
C
Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these condition isnotimplied.
(*) 500 mW:
≅
65
o
C derate to 300 mW by 10mW/
o
C: 65
o
C to 85
o
C
2/9
M54/M74HCT14
AC ELECTRICAL CHARACTERISTICS
(C
L
= 50 pF, Input t
r
= t
f
= 6 ns)
Test Conditions
Symbol
Parameter
V
CC
(V)
4.5
4.5
T
A
= 25 C
54HC and 74HC
Min. Typ. Max.
8
19
5
45
15
30
10
o
Value
-40 to 85
o
C -55 to 125
o
C
74HC
54HC
Min. Max. Min. Max.
19
38
10
22
45
10
Unit
t
TLH
t
THL
t
PLH
t
PHL
C
IN
C
PD
(*)
Output Transition
Time
Propagation
Delay Time
Input Capacitance
Power Dissipation
Capacitance
ns
ns
pF
pF
(*) C
PD
is defined as the value of the IC’s internal equivalent capacitance which is calculated from the operating current consumption without load.
(Refer to Test Circuit). Average operting current can be obtained by the following equation. I
CC
(opr) = C
PD
•V
CC
•f
IN
+ I
CC
SWITCHING CHARACTERISTICS TEST CIRCUIT
TEST CIRCUIT I
CC
(Opr.)
INPUT WAVEFORM IS THE SAME AS THAT IN CASE OF SWITCHING CHARACTERISTICS TEST.
4/9
