BCM88230
®
Brief
SUMMARY OF BENEFITS
•
A part of the XGS Core™ Fabric solution
•
Up to 2.4 GB of DDR3 SDRAM
•
Deep buffering for guaranteed goodput
FABRIC INTERFACE WITH INTEGRATED TRAFFIC
MANAGEMENT
FEATURES
•
Third-generation Fabric Interface and Traffic Manager,
supporting 50 Gbps of wirespeed bandwidth per device and
scalable up to 11 Tbps of total fabric bandwidth in the system
•
Virtual Output Queuing (VOQ) and Subscriber Queuing (SQ)
•
Patented VOQ fabric architecture
•
Administers Service Level Agreements (SLA)
•
Bandwidth guarantees for all VOQs
•
Advanced hierarchical traffic scheduler
•
SLA guarantees for carrier Ethernet
•
Integrated counters and queue state
•
Significantly reduces overall BOM costs (no FPGA/SRAM)
•
Broadcom
®
SerDes designed to drive core chassis backplanes
•
Both XMIT and RCV equalization (DFE)
•
Direct connectivity to StrataXGS devices
•
Widest Range of Optimized Solutions
•
SerDes operates at up to 6.5625G with 97% efficiency.
•
HiGig2™ interfaces for connection to StrataXGS
®
devices.
•
Off-chip packet buffer in DDR3 SDRAM
•
Hardware-based lossless failover with auto-switchover (fault
tolerant)
•
Pin-compatible with BCM88235
•
Maximum hardware reuse for different scale designs
•
Guarantees for jitter and latency
•
Enables converged packet optical systems
APPLICATIONS
•
Data Center Core, Aggregation, and Top of Rack Solutions—
Deep Buffering
•
Metro Aggregation—Hierarchical
•
Carrier Access—SLA Guarantees
•
Enterprise Core—Scalable Fabric
•
Packet Optical—Converged TDM and Packet Fabric
OVERVIEW
HiGig2
XAUI
HiGig2
XAUI
HiGig2
XAUI
HiGig2
XAUI
Ingress Processing Engine
DDR3 SDRAM
Packet
Buffer
Queue Manager
H-QoS Scheduler
Egress Processing Engine
Process
Mgmt
Fabric Interface
PCIe™
Fabric SerDes 6.5625 Gbps
BCM88230 Functional Block Diagram
The BCM88230 XGS Core Fabric Interface with Integrated Traffic
Management is the latest member of the XGS Core Fabric family.
The BCM88230 integrates packet buffering, traffic management, and a
high-speed switch fabric interface. It provides four HiGig2 interfaces for
connection to packet processor devices, such as the BCM56620 family
of StrataXGS switch devices or the BCM88025 family of network
processors. These HiGig2 interfaces support channelized flow control.
The BCM88230 communicates with the BCM88130 fabric via fabric
SerDes that operates at up to 6.5625 Gbps.
The BCM88230 is used with the BCM88130 to create the total solution
of the XGS Core Fabric.
