Datasheet> All Categories > Discrete semiconductor> diode> 36MB5APBF

36MB5APBF: DescriptionBridge Rectifier Diode, 1 Phase, 35A, 50V V(RRM), Silicon; CategoryDiscrete semiconductor diode; File Size86KB，6 Pages; ManufacturerInternational Rectifier （ Infineon ）; Websitehttp://www.irf.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

36MB5APBF Overview

Bridge Rectifier Diode, 1 Phase, 35A, 50V V(RRM), Silicon

36MB5APBF Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	International Rectifier （ Infineon ）
package instruction	R-PUFM-D4
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	UL APPROVED
Shell connection	ISOLATED
Configuration	BRIDGE, 4 ELEMENTS
Diode component materials	SILICON
Diode type	BRIDGE RECTIFIER DIODE
Maximum forward voltage (VF)	1.14 V
JESD-30 code	R-PUFM-D4
Maximum non-repetitive peak forward current	500 A
Number of components	4
Phase	1
Number of terminals	4
Maximum operating temperature	150 °C
Minimum operating temperature	-40 °C
Maximum output current	35 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	50 V
Maximum reverse current	0.00001 µA
surface mount	NO
Terminal form	SOLDER LUG
Terminal location	UPPER
Maximum time at peak reflow temperature	40
Base Number Matches	1

Preview

Download Datasheet

View All

Bulletin I2715 rev. G 08/01

MB SERIES

SINGLE PHASE BRIDGE

Power Modules

Features

Universal, 3 way terminals:

push-on, wrap around or solder

High thermal conductivity package,

electrically insulated case

Center hole fixing

Excellent power/volume ratio

UL E 62320 approved

Nickel plated terminals solderable as per MIL-STD-202E Method

208C; solder: Sn/Pb (60/40); solder temperature: 235-260°C

flux: Alpha 6295H

max. time: 8-10 secs

25 A

35 A

Description

A range of extremely compact, encapsulated single

phase bridge rectifiers offering efficient and reli-

able operation. They are intended for use in general

purpose and instrumentation applications.

Major Ratings and Characteristics

Parameters 26MB-A

@ T

FSM

@ 50Hz

@ 60Hz

@ 50Hz

@ 60Hz

RRM

range

400

420

790

725

36MB-A

475

500

1130

1030

Units

50 to 1600

- 40 to 150

www.irf.com
