5-1437559-9 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> switch> 5-1437559-9

5-1437559-9: DescriptionTOGGLE SWITCH, SPDT, LATCHED, THROUGH HOLE-RIGHT ANGLE; CategoryMechanical and electronic products switch; File Size104KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

5-1437559-9 Overview

TOGGLE SWITCH, SPDT, LATCHED, THROUGH HOLE-RIGHT ANGLE

5-1437559-9 Parametric

Parameter Name	Attribute value
Brand Name	Alcoswitch
Reach Compliance Code	unknow
ECCN code	EAR99
Actuator type	LONG OR SHORT BAT
body width	8 mm
body height	13 mm
Body length or diameter	9.23 mm
Contact (AC) maximum rated R load	6A@125VAC
Maximum contact current (AC)	6 A
Maximum contact voltage (AC)	125 V
Electrical life	50000 Cycle(s)
JESD-609 code	e4
Manufacturer's serial number	1437559
Installation features	THROUGH HOLE-RIGHT ANGLE
Maximum operating force	14.71 N
Maximum operating temperature	85 °C
Minimum operating temperature	-20 °C
seal	EPOXY TERMINAL SEALED
surface mount	NO
Switch action	LATCHED
switch function	SPDT
Switch type	TOGGLE SWITCH
Terminal surface	SILVER
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Switches

Product Feature Selector

> Product Details

MTM8106EVRA Product Details

Live Product Chat

Product View

Toggle Switches

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

MTM8106EVRA

(5-1437559-9)

T E I nternal N umber: 5 - 1 4 3 7 5 5 9 - 9

Product Highlights:

MTM Series

Single Pole - Double Throw C onfiguration (Pole-Throw)

C urrent Rating = 6 Amps.

Mount Style = Through-Hole

Termination Type = Printed C ircuit, Vertical Right Angle

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

SWITC H (MTM8106X & 206X-RA)

(PDF, English)

Catalog Pages/Data Sheets:

ALC OSWITC H PRODUC TS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

C onfiguration (Pole-Throw) = Single Pole - Double Throw

Termination Type = Printed C ircuit, Vertical Right Angle

C omment = UL available when ordering - consult factory.

Electrical Characteristics:

C urrent Rating (Amps.) = 6

Termination Related Features:

Seal Type = Terminal Seal (Insert Molded)

Body Related Features:

Series = MTM

Mount Style = Through-Hole

Flammability Rating = UL 94V-0

Contact Related Features:

C ontact Plating = Gold Flash over Silver

Housing Related Features:

Toggle Style = Baton Short

Toggle Length (mm [in]) = 6.86 [0.270]

Process Sealed = No

Bushing Style = Unthreaded

Bushing Type = .250

Configuration Related Features:

Operating Function

= On Off On

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

Other:

Brand = Alcoswitch

Additional Information:

Product Line Information

5-1437559-9 Related Products

	5-1437559-9	MTM8106EVRA
Description	TOGGLE SWITCH, SPDT, LATCHED, THROUGH HOLE-RIGHT ANGLE	TOGGLE SWITCH, SPDT, LATCHED, THROUGH HOLE-RIGHT ANGLE
Brand Name	Alcoswitch	Alcoswitch
Reach Compliance Code	unknow	unknown
ECCN code	EAR99	EAR99
Actuator type	LONG OR SHORT BAT	LONG OR SHORT BAT
body width	8 mm	8 mm
body height	13 mm	13 mm
Body length or diameter	9.23 mm	9.23 mm
Contact (AC) maximum rated R load	6A@125VAC	6A@125VAC
Maximum contact current (AC)	6 A	6 A
Maximum contact voltage (AC)	125 V	125 V
Electrical life	50000 Cycle(s)	50000 Cycle(s)
JESD-609 code	e4	e4
Manufacturer's serial number	1437559	MTM
Installation features	THROUGH HOLE-RIGHT ANGLE	THROUGH HOLE-RIGHT ANGLE
Maximum operating force	14.71 N	14.71 N
Maximum operating temperature	85 °C	85 °C
Minimum operating temperature	-20 °C	-20 °C
seal	EPOXY TERMINAL SEALED	EPOXY TERMINAL SEALED
surface mount	NO	NO
Switch action	LATCHED	LATCHED
switch function	SPDT	SPDT
Switch type	TOGGLE SWITCH	TOGGLE SWITCH
Terminal surface	SILVER	SILVER
Termination type	SOLDER	SOLDER
