MIL-W-16878E (TYPE EE)
††
UL 1180
200°C, 1000 VOLT
HOOK-UP WIRE
TFE TEFLON
®
INSULATION
C
ERTIFIED
P
ERFORMANCE
–
H
IGH
-R
ELIABILITY
TFE T
EFLON
I
NSULATION
®
Alpha’s TFE Teflon wire family includes a full range of
sizes, colors, conductor types and voltage ratings for
both commercial (UL styles) and high reliability military
OEM products.
Alpha’s TFE Teflon is rated for continuous operation in
temperatures from –60°C to 200°C and retains its
exceptional toughness and flexibility within this range.
TFE Teflon is not degraded by chemicals which makes it
ideal for use in harsh environments. Teflon is widely
regarded as the ultimate high performance wire insulation
material for environments characterized by extreme thermal
or chemical conditions.
Alpha
Part No.
5874
5875
5876
5877
5878
5879
5879/12
5879/10
5879/8†
Type
Conductor Insul. Thickness Diameter
Designation AWG Strand Inches mm Inches mm
EE-24
EE-22
EE-20
EE-18
EE-16
EE-14
EE-12
EE-10
EE-84
24
22
20
18
16
14
12
10
8
19/36
19/34
19/32
19/30
19/29
19/27
19/25
37/26
133/29
0.014
0.014
0.014
0.014
0.014
0.017
0.017
0.017
0.020
0,35
0,35
0,35
0,35
0,35
0,43
0,43
0,43
0,50
0.052
0.059
0.067
0.078
0.086
0.105
0.124
0.146
0.206
1,32
1,49
1,70
1,98
2,18
2,67
3,15
3,70
5,23
Stock
Color*
1–10
1–10
1–10
1–10
1–19
1–19
1–19
1–19
1–19
177
C
HOOSE
TFE T
EFLON
F
OR
:
®
*See color chart below
††Not
UL AWM 1180 – AWM 1180 requires that 18AWG thru 10AWG have a
temperature marker.
††All product supplied is to the MIL-W-16878 E revision. Revision F product
can be supplied upon request, subject to minimum order quantity and lead
time requirements.
Teflon
®
is a registered trademark of E.I. DuPont
Resistance To All Chemicals
s
High Temperature Use Up To 200°C
s
Low Coefficient of Friction
s
Outstanding Electrical Properties
s
TFE T
EFLON
A
PPLICATIONS
:
®
Military Harnessing
Medical Electronics
s
Power Supply Lead Wire
s
Appliance Wiring
s
s
C
HARACTERISTICS
OPERATING TEMPERATURE:
s
–60°C to 200°C
VOLTAGE RATING:
s
1000 Volt (MIL), 300 Volt (UL)
PRODUCT DESCRIPTION:
s
Conductor: Stranded Silver-Plated Copper
s
Insulation: Color-Coded, Extruded TFE Teflon
S
PECIFICATIONS
s
s
UL AWM Style 1180
MIL-W-16878E Type EE
®
A
VAILABILITY
s
100 ft (30,5m), 1000 ft (305m) put-ups
1000 ft put-ups may contain multiple lengths
*STOCK
COLOR CHART
1–White
2–Black
3–Red
4–Green
5–Yellow
6–Blue
7–Brown
8–Orange
9–Gray
10–Violet (purple)
Web Site: www.alphawire.com
Email: info@alphawire.com
Toll Free: 1-800-52 ALPHA • Telephone: 908-925-8000 • Fax: 908-925-6923
Europe/UK Telephone: +44 (0) 1932 772422 • Europe/UK Fax: +44 (0) 1932 772433
HOOK-UP WIRE
HOOK-UP WIRE KITS
H
OOK
-U
P
W
IRE
K
ITS
Alpha’s Hook-Up Wire Kits contain an assortment of
100 ft (30,5m) spools of hook-up wire suitable for
military or UL/CSA applications. These kits have been
designed for use by technicians, engineers and designers
in the R & D lab or maintenance shop.
Each kit contains five spools of hook-up wire in a unique,
rack-mounted, transparent dispensing tube. The tube
and rack system keeps hook-up wire neat, clean and
conveniently at hand.
Mounts on Bench
UL 1007/1569
CSA TR-64
MIL-W-76B, TYPE MW
tem
Dispensing Sys
A Unique Wire cians and Designers.
Techni
llable
for Engineers,
Organized • Refi
Stays Clean and
or Wall • Wire
178
e Spool
Contains: Fiv
penser Kit
e Stripper
y Wir
-U
•
Wire Dis
Hook
of Wire
p
Durable Transparent Dispenser • Qualit
s
C
HOOSE
H
OOK
-U
P
W
IRE
K
ITS
F
OR
:
Convenient, Wire Dispensing System
s
Five Assorted Hook-Up Wire Colors
s
Includes Cut and Strip Tool
s
Uses Standard Alpha Hook-Up Wire
s
Spools When Refills Are Required
s
Alpha
Part No.
HU-KIT-10
(22 AWG)
Contents
MIL-W-76B Type MW / White
MIL-W-76B Type MW / Black
MIL-W-76B Type MW / Red
MIL-W-76B Type MW / Green
MIL-W-76B Type MW / Blue
Cut and Strip Tool
Quantity
Ft.
m
100
100
100
100
100
30,5
30,5
30,5
30,5
30,5
Reorder
No.
1551
1551
1551
1551
1551
C
HARACTERISTICS
OPERATING TEMPERATURE:
s
–40°C to 80°C (HU-KIT-10, 30)
s
–40°C to 105°C (HU-KIT-20, 40)
VOLTAGE RATING:
s
1000 Volt (HU-KIT-10, 30)
s
300 Volt (HU-KIT-20, 40)
PRODUCT DESCRIPTION:
s
Conductor:
Stranded Tinned Copper
s
Insulation:
Color-Coded PVC
s
AWG Size:
22 AWG (HU-KIT-10, 20)
24 AWG (HU-KIT-30, 40)
Alpha
Part No.
HU-KIT-20
(22 AWG)
Contents
UL 1007/1569, CSA TR-64 / White
UL 1007/1569, CSA TR-64 / Black
UL 1007/1569, CSA TR-64 / Red
UL 1007/1569, CSA TR-64 / Green
UL 1007/1569, CSA TR-64 / Blue
Cut and Strip Tool
Quantity
Ft.
m
100
100
100
100
100
30,5
30,5
30,5
30,5
30,5
Reorder
No.
3051
3051
3051
3051
3051
Alpha
Part No.
HU-KIT-30
(24 AWG)
Contents
MIL-W-76B Type MW / White
MIL-W-76B Type MW / Black
MIL-W-76B Type MW / Red
MIL-W-76B Type MW / Green
MIL-W-76B Type MW / Blue
Cut and Strip Tool
Quantity
Ft.
m
100
100
100
100
100
30,5
30,5
30,5
30,5
30,5
Reorder
No.
1550
1550
1550
1550
1550
S
PECIFICATIONS
UL AWM Styles 1007 and 1569
s
CSA TR-64
s
MIL-W-76B, Type MW
s
Alpha
Part No.
HU-KIT-40
(24 AWG)
Contents
UL 1007/1569, CSA TR-64 / White
UL 1007/1569, CSA TR-64 / Black
UL 1007/1569, CSA TR-64 / Red
UL 1007/1569, CSA TR-64 / Green
UL 1007/1569, CSA TR-64 / Blue
Cut and Strip Tool
Quantity
Ft.
m
100
100
100
100
100
30,5
30,5
30,5
30,5
30,5
Reorder
No.
3050
3050
3050
3050
3050
®
