342725-1: Description2 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER; CategoryThe connector The connector; File Size116KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

342725-1 Overview

2 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER

342725-1 Parametric

Parameter Name	Attribute value
Objectid	1416455937
Reach Compliance Code	unknown
Other features	SHIELDED
Connector type	BOARD CONNECTOR
Contact to complete cooperation	TIN
Contact completed and terminated	TIN
Contact point gender	MALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	342725
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	2
UL Flammability Code	94V-2

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PC B C onnectors - Wire to Board - Power

Product Feature Selector

> Product Details

342725-1 Product Details

Live Product Chat

Product View

MTA, CST-100 II, MT-6 and SL Connectors and Headers

Not re vie we d for R oHS C om plia nce

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

342725-1

T E I nternal N umber: 3 4 2 7 2 5 - 1

Product Highlights:

MT-7 C onnectors

Number of Positions = 2

Mating Type = Header

Wire-to-Board Application

2.54 mm C ontact C enterline Spacing

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

Automachine and General Products

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = MT-7 C onnectors

Number of Positions

= 2

Mating Type

= Header

PC B Mount Angle

= Vertical

Mating Polarization

= With

Mating C onnector Lock = Without

Four Points of C ontact

= Without

Shrouded

= Yes

Mounting Ears

= Without

Mechanical Attachment:

Panel Attachment

= Without

Termination Related Features:

Solder Tail C ontact Plating

= Tin

Contact Related Features:

C ontact C enterline Spacing (mm [in])

= 2.54 [0.100]

C ontact Mating Area Plating Material

= Tin

C ontact Base Material

= Brass

Housing Related Features:

Housing C olor = White

Housing Flammability Rating = UL 94V-2

Housing Material = Nylon

Configuration Related Features:

Backwall/Post Interruption(s)

= Without

Industry Standards:

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Conditions for Usage:

Terminate To

= Printed C ircuit Board

Operation/Application:

Application

= Wire-to-Board

Other:

Brand = AMP

Additional Information:

Product Line Information

Additional Product Images:

PC B Layout
