IS61SP6436
IS61SP6436
64K x 36 SYNCHRONOUS
PIPELINED STATIC RAM
ISSI
JULY 1999
ISSI
®
®
FEATURES
• Internal self-timed write cycle
• Individual Byte Write Control and Global Write
• Clock controlled, registered address, data and
control
• Pentium™ or linear burst sequence control
using MODE input
• Three chip enables for simple depth expansion
and address pipelining
• Common data inputs and data outputs
• Power-down control by ZZ input
• JEDEC 100-Pin TQFP and PQFP package
• Single +3.3V power supply
• Two Clock enables and one Clock disable to
eliminate multiple bank bus contention.
• Control pins mode upon power-up:
– MODE in interleave burst mode
– ZZ in normal operation mode
These control pins can be connected to GND
Q
or V
CCQ
to alter their power-up state
DESCRIPTION
The
ISSI
IS61SP6436 is a high-speed, low-power synchro-
nous static RAM designed to provide a burstable, high-
performance, secondary cache for the i486™, Pentium™,
680X0™, and PowerPC™ microprocessors. It is organized
as 65,536 words by 36 bits, fabricated with
ISSI
's advanced
CMOS technology. The device integrates a 2-bit burst counter,
high-speed SRAM core, and high-drive capability outputs into
a single monolithic circuit. All synchronous inputs pass through
registers controlled by a positive-edge-triggered single clock
input.
Write cycles are internally self-timed and are initiated by the
rising edge of the clock input. Write cycles can be from one to
four bytes wide as controlled by the write control inputs.
Separate byte enables allow individual bytes to be written.
BW1
controls DQP1 and DQ1-DQ8,
BW2
controls DQP2 and
DQ9-DQ16,
BW3
controls DQP3 and DQ17-DQ24,
BW4
controls DQP4 and DQ25-DQ32, conditioned by
BWE
being
LOW. A LOW on
GW
input would cause all bytes to be written.
Bursts can be initiated with either
ADSP
(Address Status
Processor) or
ADSC
(Address Status Cache Controller) input
pins. Subsequent burst addresses can be generated inter-
nally by the IS61SP6436 and controlled by the
ADV
(burst
address advance) input pin.
Asynchronous signals include output enable (
OE
), sleep mode
input (ZZ), clock (CLK) and burst mode input (MODE). A HIGH
input on the ZZ pin puts the SRAM in the power-down state.
When ZZ is pulled LOW (or no connect), the SRAM normally
operates after three cycles of the wake-up period. A LOW
input, i.e., GND
Q
, on MODE pin selects LINEAR Burst. A V
CCQ
(or no connect) on MODE pin selects INTERLEAVED Burst.
FAST ACCESS TIME
Symbol
t
KQ
t
KC
Parameter
Clock Access Time
Cycle Time
Frequency
-133
5
7.5
133
-117
5
8.5
117
-5
5
10
100
-6
6
12
83
-7
7
13
75
-8
8
15
66
Unit
ns
ns
MHz
This document contains PRELIMINARY data. ISSI reserves the right to make changes to its products at any time without notice in order to improve design and supply the best possible product.
We assume no responsibility for any errors which may appear in this publication. © Copyright 1997, Integrated Silicon Solution, Inc.
Integrated Silicon Solution, Inc.
SR029-1C
08/11/99
1
IS61SP6436
TRUTH TABLE
Operation
Deselected, Power-down
Deselected, Power-down
Deselected, Power-down
Deselected, Power-down
Deselected, Power-down
Read Cycle, Begin Burst
Read Cycle, Begin Burst
Write Cycle, Begin Burst
Read Cycle, Begin Burst
Read Cycle, Begin Burst
Read Cycle, Continue Burst
Read Cycle, Continue Burst
Read Cycle, Continue Burst
Read Cycle, Continue Burst
Write Cycle, Continue Burst
Write Cycle, Continue Burst
Read Cycle, Suspend Burst
Read Cycle, Suspend Burst
Read Cycle, Suspend Burst
Read Cycle, Suspend Burst
Write Cycle, Suspend Burst
Write Cycle, Suspend Burst
Address
Used
None
None
None
None
None
External
External
External
External
External
Next
Next
Next
Next
Next
Next
Current
Current
Current
Current
Current
Current
ISSI
CE
H
L
L
L
L
L
L
L
L
L
X
X
H
H
X
H
X
X
H
H
X
H
®
CE2
X
X
H
X
H
L
L
L
L
L
X
X
X
X
X
X
X
X
X
X
X
X
CE2
X
L
X
L
X
H
H
H
H
H
X
X
X
X
X
X
X
X
X
X
X
X
ADSP ADSC ADV WRITE
X
L
L
H
H
L
L
H
H
H
H
H
X
X
H
X
H
H
X
X
H
X
L
X
X
L
L
X
X
L
L
L
H
H
H
H
H
H
H
H
H
H
H
H
X
X
X
X
X
X
X
X
X
X
L
L
L
L
L
L
H
H
H
H
H
H
X
X
X
X
X
X
X
L
H
H
H
H
H
H
L
L
H
H
H
H
L
L
OE
X
X
X
X
X
L
H
X
L
H
L
H
L
H
X
X
L
H
L
H
X
X
DQ
High-Z
High-Z
High-Z
High-Z
High-Z
Q
High-Z
D
Q
High-Z
Q
High-Z
Q
High-Z
D
D
Q
High-Z
Q
High-Z
D
D
Notes:
1. All inputs except
OE
must meet setup and hold times for the Low-to-High transition of clock (CLK).
2. Wait states are inserted by suspending burst.
3. X means don't care.
WRITE
=L means any one or more byte write enable signals (
BW
1-
BW
4) and
BWE
are LOW or
GW
is LOW.
WRITE
=H means all byte write enable signals are HIGH.
4. For a Write operation following a Read operation,
OE
must be HIGH before the input data required setup time and held HIGH
throughout the input data hold time.
5.
ADSP
LOW always initiates an internal READ at the Low-to-High edge of clock. A WRITE is performed by setting one or more
byte write enable signals and
BWE
LOW or
GW
LOW for the subsequent L-H edge of clock.
PARTIAL TRUTH TABLE
Function
READ
READ
WRITE Byte 1
WRITE All Bytes
WRITE All Bytes
GW
H
H
H
H
L
BWE
H
L
L
L
X
BW1
X
H
L
L
X
BW2
X
H
H
L
X
BW3 BW4
X
H
H
L
X
X
H
H
L
X
4
Integrated Silicon Solution, Inc.
SR029-1C
08/11/99
IS61SP6436
INTERLEAVED BURST ADDRESS TABLE (MODE = V
CCQ
or No Connect)
External Address
A1 A0
00
01
10
11
1st Burst Address
A1 A0
01
00
11
10
2nd Burst Address
A1 A0
10
11
00
01
3rd Burst Address
A1 A0
11
10
01
00
ISSI
®
LINEAR BURST ADDRESS TABLE (MODE = GND
Q
)
0,0
A1', A0' = 1,1
0,1
1,0
ABSOLUTE MAXIMUM RATINGS
(1)
Symbol
T
BIAS
T
STG
P
D
I
OUT
V
IN
, V
OUT
V
IN
V
CC
Parameter
Temperature Under Bias
Storage Temperature
Power Dissipation
Output Current (per I/O)
Voltage Relative to GND for I/O Pins
Voltage Relative to GND for
for Address and Control Inputs
Voltage on Vcc Supply Relatiive to GND
Value
Unit
–40 to +85
°C
–55 to +150
°C
1.8
W
100
mA
–0.5 to V
CCQ
+ 0.3
V
–0.5 to 5.5
V
–0.5 to 4.6
V
Notes:
1. Stress greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause
permanent damage to the device. This is a stress rating only and functional operation of the
device at these or any other conditions above those indicated in the operational sections of
this specification is not implied. Exposure to absolute maximum rating conditions for extended
periods may affect reliability.
2. This device contains circuity to protect the inputs against damage due to high static voltages
or electric fields; however, precautions may be taken to avoid application of any voltage higher
than maximum rated voltages to this high-impedance circuit.
3. This device contains circuitry that will ensure the output devices are in High-Z at power up.
Integrated Silicon Solution, Inc.
SR029-1C
08/11/99
5
