5962-9472501MCX amplifier basic information:
5962-9472501MCX is an OPERATIONAL AMPLIFIER. The commonly used packaging method is DIP,
5962-9472501MCX amplifier core information:
How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962-9472501MCX is 2000 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the 5962-9472501MCX gain becomes 0.707 times the low-frequency gain is 92000 kHz.
The nominal supply voltage of 5962-9472501MCX is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of 5962-9472501MCX is 6000 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the op amp 0V (or close to 0V).)
Related dimensions of 5962-9472501MCX:
The width of 5962-9472501MCX is: 7.62 mm and the length is 19.43 mm. 5962-9472501MCX has 14 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 14
5962-9472501MCX amplifier additional information:
The corresponding JESD-30 code is: R-GDIP-T14. The packaging code of 5962-9472501MCX is: DIP. The materials used in the 5962-9472501MCX package are mostly CERAMIC and GLASS-SEALED. The package shape is RECTANGULAR. The 5962-9472501MCX package pin format is: IN-LINE.
Its terminal form is: THROUGH-HOLE. The maximum seat height is 5.08 mm.
5962-9472501MCX amplifier basic information:
5962-9472501MCX is an OPERATIONAL AMPLIFIER. The commonly used packaging method is DIP,
5962-9472501MCX amplifier core information:
How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962-9472501MCX is 2000 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the 5962-9472501MCX gain becomes 0.707 times the low-frequency gain is 92000 kHz.
The nominal supply voltage of 5962-9472501MCX is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of 5962-9472501MCX is 6000 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the op amp 0V (or close to 0V).)
Related dimensions of 5962-9472501MCX:
The width of 5962-9472501MCX is: 7.62 mm and the length is 19.43 mm. 5962-9472501MCX has 14 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 14
5962-9472501MCX amplifier additional information:
The corresponding JESD-30 code is: R-GDIP-T14. The packaging code of 5962-9472501MCX is: DIP. The materials used in the 5962-9472501MCX package are mostly CERAMIC and GLASS-SEALED. The package shape is RECTANGULAR. The 5962-9472501MCX package pin format is: IN-LINE.
Its terminal form is: THROUGH-HOLE. The maximum seat height is 5.08 mm.
| Parameter Name | Attribute value |
| Maker | Fairchild |
| Parts packaging code | DIP |
| package instruction | DIP, |
| Contacts | 14 |
| Reach Compliance Code | unknown |
| ECCN code | EAR99 |
| Amplifier type | OPERATIONAL AMPLIFIER |
| Nominal Common Mode Rejection Ratio | 63 dB |
| Maximum input offset voltage | 6000 µV |
| JESD-30 code | R-GDIP-T14 |
| length | 19.43 mm |
| Negative supply voltage upper limit | -16.5 V |
| Nominal Negative Supply Voltage (Vsup) | -15 V |
| Number of functions | 2 |
| Number of terminals | 14 |
| Package body material | CERAMIC, GLASS-SEALED |
| encapsulated code | DIP |
| Package shape | RECTANGULAR |
| Package form | IN-LINE |
| Certification status | Not Qualified |
| Maximum seat height | 5.08 mm |
| Nominal slew rate | 2000 V/us |
| Supply voltage upper limit | 16.5 V |
| Nominal supply voltage (Vsup) | 15 V |
| surface mount | NO |
| Terminal form | THROUGH-HOLE |
| Terminal pitch | 2.54 mm |
| Terminal location | DUAL |
| Nominal Uniform Gain Bandwidth | 92000 kHz |
| width | 7.62 mm |
| Base Number Matches | 1 |
| 5962-9472501MCX | 5962-9472502MPX | 5962-9472501M2X | |
|---|---|---|---|
| Description | Operational Amplifier, 2 Func, 6000uV Offset-Max, CDIP14, DIP-14 | Operational Amplifier, 2 Func, 6000uV Offset-Max, CDIP8, DIP-8 | Operational Amplifier, 2 Func, 6000uV Offset-Max, CQCC20, LCC-20 |
| Maker | Fairchild | Fairchild | Fairchild |
| Parts packaging code | DIP | DIP | QLCC |
| package instruction | DIP, | DIP, | QCCN, |
| Contacts | 14 | 8 | 20 |
| Reach Compliance Code | unknown | unknown | unknown |
| ECCN code | EAR99 | EAR99 | EAR99 |
| Amplifier type | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER |
| Nominal Common Mode Rejection Ratio | 63 dB | 63 dB | 63 dB |
| Maximum input offset voltage | 6000 µV | 6000 µV | 6000 µV |
| JESD-30 code | R-GDIP-T14 | R-GDIP-T8 | S-CQCC-N20 |
| Negative supply voltage upper limit | -16.5 V | -16.5 V | -16.5 V |
| Nominal Negative Supply Voltage (Vsup) | -15 V | -15 V | -15 V |
| Number of functions | 2 | 2 | 2 |
| Number of terminals | 14 | 8 | 20 |
| Package body material | CERAMIC, GLASS-SEALED | CERAMIC, GLASS-SEALED | CERAMIC, METAL-SEALED COFIRED |
| encapsulated code | DIP | DIP | QCCN |
| Package shape | RECTANGULAR | RECTANGULAR | SQUARE |
| Package form | IN-LINE | IN-LINE | CHIP CARRIER |
| Certification status | Not Qualified | Not Qualified | Not Qualified |
| Maximum seat height | 5.08 mm | 5.08 mm | 1.905 mm |
| Nominal slew rate | 2000 V/us | 2000 V/us | 2000 V/us |
| Supply voltage upper limit | 16.5 V | 16.5 V | 16.5 V |
| Nominal supply voltage (Vsup) | 15 V | 15 V | 15 V |
| surface mount | NO | NO | YES |
| Terminal form | THROUGH-HOLE | THROUGH-HOLE | NO LEAD |
| Terminal pitch | 2.54 mm | 2.54 mm | 1.27 mm |
| Terminal location | DUAL | DUAL | QUAD |
| Nominal Uniform Gain Bandwidth | 92000 kHz | 92000 kHz | 92000 kHz |
| width | 7.62 mm | 7.62 mm | 8.89 mm |
| Base Number Matches | 1 | 1 | 1 |
| length | 19.43 mm | - | 8.89 mm |
