5650635013 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 5650635013

5650635013: DescriptionRESISTOR, POTENTIOMETER, CARBON FILM, 1 TURN(S), 0.2W, 470000ohm, ROHS COMPLIANT; CategoryPassive components The resistor; File Size114KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

5650635013 Overview

RESISTOR, POTENTIOMETER, CARBON FILM, 1 TURN(S), 0.2W, 470000ohm, ROHS COMPLIANT

5650635013 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1670463459
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Actuator direction	HORIZONTAL
Actuator type	SHAFT
gang number	1
Manufacturer's serial number	51
Installation features	THROUGH HOLE MOUNT
Number of terminals	3
number of turns	1
Package shape	RECTANGULAR PACKAGE
Rated power dissipation(P)	0.2 W
resistance	470000 Ω
resistance law	LINEAR
Resistor type	POTENTIOMETER
surface mount	NO
technology	CARBON FILM
Terminal shape	FLAT
Tolerance	20%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Resistors

Product Feature Selector

> Product Details

5650635013 Product Details

Live Product Chat

Variable Resistors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5650635013

(1-1624229-1)

T E I nternal N umber: 1 - 1 6 2 4 2 2 9 - 1

Product Highlights:

Variable Resistor

Resistor Type = Potentiometer

Resistance Selection = K ?

Resistance = 470K ?

Power Rating = .20 W

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

Spindle Operated Potentiometers - Type 51 Series - T...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Variable Resistor

Resistor Type

= Potentiometer

Resistance (?)

= 470K

Element

= C arbon

Sealed

= No

Mount Angle

= Vertical

Termination Type

= PC B Terminations

Electrical Characteristics:

Resistance Selection (?) = K

Power Rating (W)

= 0.20

Tolerance (%)

= 20

Termination Related Features:

Termination Post Orientation

= In Line

Body Related Features:

Series

= 51

Switch Type

= Rotary SPST

Shaft Style

= Plain, 6mm x 30mm

Package, C omponent Size

= 12.5 x 15.8

Configuration Related Features:

Sections

= Single

Adjustment Location

= Side

Adjustment Style

= Spindle With Switch

Operating Function

= Single Turn

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

Temperature C oefficient (ppm/?C )

= 500

Other:

Brand = C itec

Additional Information:

Product Line Information
