34THES1BWD2S22

Description
Position, Rotary, Hall Effect Sensor, POSITION, ROTARY SENSOR-HALL EFFECT, CYLINDRICAL, ROHS COMPLIANT PACKAGE
CategoryThe sensor    Sensor/transducer
File Size131KB,6 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Environmental Compliance
Download Datasheet Parametric View All

34THES1BWD2S22 Overview

Position, Rotary, Hall Effect Sensor, POSITION, ROTARY SENSOR-HALL EFFECT, CYLINDRICAL, ROHS COMPLIANT PACKAGE

34THES1BWD2S22 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerVishay
Reach Compliance Codeunknown
Other featuresOVER VOLTAGE PROTECTION, REVERSE VOLTAGE PROTECTION
body height22.1 mm
Body length or diameter22.2 mm
shellANODIZED ALUMINUM
Linearity(%)0.5 %
Maximum working current16 mA
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Output interface type3-WIRE INTERFACE
Output typeDIGITAL VOLTAGE
Package Shape/FormCYLINDRICAL
Sensor/Transducer TypeROTARY POSITION SENSOR,HALL EFFECT
Maximum supply voltage5.5 V
Minimum supply voltage4.5 V
Base Number Matches1
34 THE
www.vishay.com
Vishay Spectrol
Ten Turns Servo or Bushing Mount Hall Effect
Sensor in Size 09 (22.2 mm)
FEATURES
• All electrical angles available up to: 3600°
• Accurate linearity down to: ± 0.5 %
• Very long life: 50M cycles for servo, 10M cycles
for bushing
• Non contacting technology: Hall effect; true power on
sensor
• Model dedicated to applications requiring long life
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
ELECTRICAL SPECIFICATIONS
PARAMETER
Electrical angle
Linearity
Supply voltage
Supply current
Output signal
Over voltage protection
Reverse voltage protection
Load resistance recommended
Hysteresis static
STANDARD
10 turns 3600°
±1%
5 V
DC
± 10 %
< 16 mA for single
SPECIAL
Any other angle upon request
± 0.5 %
Other upon request
< 32 mA for redundant
Analog ratiometric 1 % to 99 % of V
supply
(other on request)
or PWM 1 kHz, 10 % to 90 % duty cycle or SPI binary on 5 V or binary on 3.3 V
+ 20 V
DC
- 10 V
DC
Min. 1 k for analog output and PWM output
10° on drive shaft
MECHANICAL SPECIFICATIONS
PARAMETER
Mechanical travel
Bearing type
Standard
Resolution
3600° continuous
A sleeve bearing for bushing model/2 ball bearings for servo model
IP 50; other on request
12 bits for analog and PWM, 14 bits for SPI
ORDERING INFORMATION/DESCRIPTION
34 THE
MODEL
B
MOUNTING
TYPE
B:
Bushing
S:
Servo
1
NUMBER OF
SIGNALS
A
LINEARITY
T
OUTPUT
TYPE
T:
Turrets
Z:
Custom
W:
Wires
A
OUTPUT
SIGNAL
2S22
SHAFT
TYPE
XXXX
BO 1
e1
SPECIAL
LEAD
PACKAGING
REQUEST
FINISH
Box of
1 piece
1:
Single
A:
± 1 %
2:
Redundant
B:
± 0.5 %
(crossed laws)
A:
Analog CW
2:
3.175 mm
B:
Analog CCW
9:
Special
C:
PWM CW
P:
Plain
D:
PWM CCW
S:
Slotted
E:
SPI CW
(1)
Z:
Other type
F:
SPI CCW
(1)
Z:
Other output
Shaft length from mounting face standard: 22 mm
Note
(1)
SPI output
output type: Wires
SAP PART NUMBERING GUIDELINES
34 THE
MODEL
S
SERVO
TYPE
2
2 OUTPUT
SIGNALS
B
LINEARITY
B: ± 0.5 %
Revision: 02-Apr-12
Document Number: 57114
1
For technical questions, contact:
sfer@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
T
OUTPUT
TYPE
C
OUTPUT
SIGNAL
2P12
SHAFT
TYPE
XXXX
SPECIAL
REQUEST
