54LS27DM datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> 54LS27DM

54LS27DM: DescriptionNOR Gate, LS Series, 3-Func, 3-Input, TTL, CDIP14, DIP-14; Categorylogic logic; File Size704KB，2 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

54LS27DM Overview

NOR Gate, LS Series, 3-Func, 3-Input, TTL, CDIP14, DIP-14

54LS27DM Parametric

Parameter Name	Attribute value
Parts packaging code	DIP
package instruction	DIP,
Contacts	14
Reach Compliance Code	unknown
series	LS
JESD-30 code	R-GDIP-T14
Logic integrated circuit type	NOR GATE
Number of functions	3
Number of entries	3
Number of terminals	14
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
Maximum seat height	5.08 mm
surface mount	NO
technology	TTL
Temperature level	MILITARY
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	7.62 mm
Base Number Matches	1
