3611T4R7K

Description
General Purpose Inductor, 4.7uH, 10%, 1 Element, Ferrite-Core, SMD
CategoryPassive components    inductor
File Size101KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric Compare View All

3611T4R7K Overview

General Purpose Inductor, 4.7uH, 10%, 1 Element, Ferrite-Core, SMD

3611T4R7K Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
Reach Compliance Codeunknown
ECCN codeEAR99
core materialFERRITE
DC Resistance1.55 Ω
Nominal inductance(L)4.7 µH
Inductor ApplicationsRF INDUCTOR
Inductor typeGENERAL PURPOSE INDUCTOR
Manufacturer's serial number3611
Number of functions1
Number of terminals2
Maximum operating temperature100 °C
Minimum operating temperature-20 °C
Minimum quality factor (at nominal inductance)25
Maximum rated current0.125 A
self resonant frequency55 MHz
Shape/Size DescriptionRECTANGULAR PACKAGE
shieldNO
surface mountYES
Terminal locationDUAL ENDED
Terminal shapeWRAPAROUND
Test frequency7.96 MHz
Tolerance10%
Base Number Matches1
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Passive C omponents
>
Product Feature Selector
> Product Details
3611T4R7K Product Details
Live Product Chat
Inductors
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3611T4R7K
(1-1624102-1)
T E I nternal N umber: 1 - 1 6 2 4 1 0 2 - 1
Product Highlights:
l
Inductor
l
Inductor Type = Molded Wirewound
l
Lead Type = Surface Mount Terminals
l
Wirewound
l
Inductance = 4.7 ?H
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
SMD C HIP INDUC TOR SERIES 3611T
(PDF, English)
Catalog Pages/Data Sheets:
l
SMD C hip Inductor - Type 3611 Series - Tyco Electron...
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Inductor
l
Inductor Type = Molded Wirewound
l
Element
= Wirewound
l
Shielded
= No
Electrical Characteristics:
l
Inductance (?H)
= 4.7
l
DC Resistance (?)
= 1.55
l
C urrent, Maximum (mA)
= 125
l
Quality Factor
= 25
l
Package Type
= Taped and Reeled
l
Tolerance (%) = 10
Body Related Features:
l
Lead Type
= Surface Mount Terminals
l
Series
= 3611
l
Packaging Style
= 1008
l
Package, C omponent Size
= 2.5 x 2.0
l
Mount Style
= Surface Mount
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Operation/Application:
l
Application
= Standard
Other:
l
Brand = Sigma Inductors
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved

3611T4R7K Related Products

3611T4R7K 1-1624102-1
Description General Purpose Inductor, 4.7uH, 10%, 1 Element, Ferrite-Core, SMD 1 ELEMENT, 4.7uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1008, ROHS COMPLIANT
Is it lead-free? Lead free Lead free
Is it Rohs certified? conform to conform to
Reach Compliance Code unknown compliant
ECCN code EAR99 EAR99
DC Resistance 1.55 Ω 1.55 Ω
Nominal inductance(L) 4.7 µH 4.7 µH
Inductor type GENERAL PURPOSE INDUCTOR GENERAL PURPOSE INDUCTOR
Manufacturer's serial number 3611 3611
Number of functions 1 1
Number of terminals 2 2
Minimum quality factor (at nominal inductance) 25 25
Maximum rated current 0.125 A 0.125 A
Shape/Size Description RECTANGULAR PACKAGE RECTANGULAR PACKAGE
shield NO NO
surface mount YES YES
Terminal location DUAL ENDED DUAL ENDED
Terminal shape WRAPAROUND WRAPAROUND
Tolerance 10% 10%
