SMD 434.0MHz SAW FILTER
AFS434S3
CHARACTERISTICS
Center Frequency Fc
Bandwidth
Insertion Loss @ Passband
Ripple @ Passband
Relative Attenuation
Fc-100 ~ Fc-40.8 MHz
Fc+40.8 ~ Fc+100 MHz
DC Voltage
Source Power
Operating Temperature
Storage Temperature
Terminating Impedance
Electrostatic Sensitive Device. Handle with precaution.
APPLICATION:
Automotive Electronics/Remote Control
| | | | | | | | | | | | | | |
3.8 x 3.8 x 1.5mm
STANDARD SPECIFICATIONS:
UNIT
MHz
MHz
dB
dB
dB
dB
V
dBm
°C
°C
-
MIN.
-
-
-
-
50
50
10
0
-10°C to +50°C
-40°C to +85°C
50Ω/0 pF
TYP.
434
Fc + 2.0
2.7
0.7
MAX.
-
-
4.5
1.5
-
-
MARKING:
- 434.00
- AF ZYX
(434.0 Frequency in MHz)
(ZY: Date code Z for month
from A to L; Y for year, I.e. 4 for 2004
X: Traceability code)
PIN NO. CONNECTIONS
2
Input
5
Output
All Others
Ground
OUTLINE DRAWING:
0.15±.008
(3.8±0.2)
0.15±.008
(3.8±0.2)
1
2
3
R0.006
(0.15)
FREQUENCY RESPONSE:
TEST CIRCUIT:
0.071
(1.80)
0.05
(1.27)
0.075
(1.9)
6
5
4
6
5
4
0.059max.
(1.5)
0.024
(0.6)
1
2
3
Dimensions: inch (mm)
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000| fax 949-546-8001
| www.abracon.com
