SERIES 28
HiPer-D
®
Contacts and Tools
75 ohm coaxial contacts
75 OHM COAX CONTACTS
Fig. 1
Pin Contact
852-086
These coax contacts snap into Glenair combo HiPer-D® size #8 cavities and can
be removed with a plastic extraction tool. Crimp termination. 75 ohm nominal
impedance, DC - 3GHz frequency range. Use with RG179 coax cable or high
bandwidth PIC cable for RS170 or SMPTE 292M video. Gold plated copper alloy,
fluoropolymer dielectric. 1000 VAC DWV rating, 3 amp current rating. Optional
sealing boot prevents moisture ingress.
These contacts are designed for use only with
Glenair Combo HiPer-D® connectors and cannot be installed in other connectors.
Contact Cable
Fig.
Type
Accommodation
1
Pin
M17/964-RG179
PIC™ V75268, V76261,
V73263
M17/964-RG179
PIC™ V75268, V76261,
V73263
.276/.272
(7.01/6.91)
Ø.188/.186 Ø.153/.151
(4.78/4.72) (3.89/3.84)
SOCKET TO MATE WITH Ø
Ø .162/.158
.021/.019 (0.53/0.48) PIN
(4.11/4.01)
A
CRIMP
RED COLOR
BAND INDICATES
75 OHM CONTACT
Part Number
Part Number
Contact and
Contact Only
Sealing Boot
852-086-01
852-086-02
852-087-01
852-087-02
852-086-01F
A Crimp Size
In.
mm.
.128 Hex 3.25 Hex
Ø 3.96
852-086-02F
Ø .156
852-087-01F
.128 Hex 3.25 Hex
Ø 3.96
Fig. 2
Socket Contact
852-087
2
Socket
852-087-02F
Ø .156
.940 (23.88) MAX.
.033/.029
(0.84/0.74)
Contact and Crimp Sleeve:
Copper alloy,
50 microinches gold over nickel.
Dielectric:
Fluoropolymer
Sealing Boot:
Thermoplastic and
Fluorosilicone
Material and Finish
Pin Contact
852-086
MATES WITH .153/.151
(3.89/3.84) PIN
.940 (23.88) MAX.
.268/.264
(6.81/6.71)
E
Impedance:
75 ohms
Frequency:
DC – 3GHz
Current Rating:
3 amps maximum
Contact Resistance:
10 milliohms
Temperature Range:
-65° to + 200° C.
Dielectric Withstanding Voltage:
1000 VAC
Insulation Resistance:
5 gigohms
Specifications
Ø.188/.186
(4.78/4.72)
Ø.021/.019
(0.53/0.48)
Ø .162/.158
(4.11/4.01)
A
CRIMP
RED COLOR
BAND INDICATES
75 OHM CONTACT
Insertion/ExtractionTool
Part Number
Socket Contact
852-087
809-132
(M81969/14-04)
TOOLING INFORMATION FOR 75 OHM CONTACTS
Part Number Type
852-086-01
852-086-02
852-087-01
852-087-02
PIN
PIN
SOCKET
SOCKET
Inner Contact Tooling
Crimp Tool
Positioner
809-015
859-098
(M22520/2-01)
Shield Crimp Sleeve Tooling
Crimp Tool
Positioner
809-129
809-130
809-133
859-100
809-129
809-130
809-133
859-100
E-6
Rev. 12.17.15
© 2015 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • Series 28 HiPer-D catalog
Dimensions in Inches (millimeters) are subject to change without notice.
SERIES 28
HiPer-D
®
Contacts and Tools
75 ohm high performance coaxial cable
75 OHM HIGH PERFORMANCE COAXIAL CABLE
FOAMED FEP DIELCTRIC
Ø .086 (2.18)
SILVER-PLATED
CONDUCTOR
Ø .019 (0.48)
FEP JACKET
Ø .122 (3.10)
TINNED COPPER BRAID
Ø .102 (2.59)
75 ohm coaxial cable for RS170 video
applications. 50 dB shielding effectiveness.
Tinned copper braid shield. Red FEP jacket.
1
PIC™ brand video cable is specially designed and manufactured for reliable
performance in aircraft systems and other harsh environments involving high
temperature, EMI and corrosive materials. Improved strength, lower attenuation
and better shielding compared with M17/94-RG179. Silver-plated conductor,
foamed FEP dielectric, tinned copper braid, FEP or ETFE jacket. Skydrol resistant,
RoHS compliant, meets FAA FAR Parts 23 and 25, Appendix F flammability,
complies with MIL-DTL-17.
Cable 1
Glenair Part No.
Ref. PIC™ Part No.
Impedance (ohms)
Shielding Effectiveness (dB)
Video Application
First Shield
Second Shield
Temperature Rating
Minimum Bend Radius
Weight (lbs/100 ft.)
Capacitance (pF/ft)
Velocity of Propagation %
Time Delay
Attenuation (dB/100 ft)
1 MHz
10 MHz
100 MHz
400 MHz
1.45 GHz
3 GHz
960-130
V75268
75
50
RS170
Cable 2
Cable 3
FOAMED FEP DIELCTRIC
Ø .086 (2.18)
SILVER-PLATED
CONDUCTOR
Ø .019 (0.48)
ETFE JACKET
Ø .122 (3.10)
75 ohm coaxial cable for RS170 video
applications. 90 dB shielding effectiveness.
100% coverage aluminized plastic foil under
tinned copper braid shield. ETFE jacket, white.
SILVER-PLATED
CONDUCTOR
Ø .019 (0.48)
2
ALUMINIZED PLASTIC
FOIL
TINNED COPPER BRAID
Ø .107 (2.72)
None
960-131
960-132
V76261
V73263
75
75
90
110
RS170
SMPTE 292M
Tinned copper braid, 95% coverage
Silver plated heli-
Aluminized film,
cal copper strip,
100% coverage
100%
-55° to +150° C
0.6 in. (15mm.)
1.1 lbs
16.0
80
1.28
Nominal
Max
0.49
0.52
1.6
1.71
5.1
5.5
10.6
11.3
21.9
23.4
33.7
36.1
-55° to +150° C
0.65 in. (16.5mm.)
1.5 lbs
16.0
80
1.28
Nominal
Max
0.43
0.58
1.4
1.6
4.5
5.0
9.6
10.6
20.0
22.0
30.9
34.0
FOAMED FEP DIELCTRIC
Ø .086 (2.18)
ETFE JACKET
Ø .125 (3.18)
75 ohm coaxial cable for SMPTE 292M video
applications. 110 dB shielding effectiveness.
100% coverage helical copper strip under tinned
copper braid shield. ETFE jacket, white.
3
SILVER PLATED
HELICAL COPPER STRIP
TINNED COPPER BRAID
Ø .107 (2.72)
-55° to +150° C
0.6 in. (15mm.)
1.2 lbs
16.0
80
1.28
Nominal
Max
0.51
0.55
1.70
1.77
5.3
5.7
11.1
11.8
23.0
24.6
35.0
37.4
E
© 2015 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • Series 28 HiPer-D catalog
Dimensions in Inches (millimeters) are subject to change without notice.
E-7
