AND190HW
Ultra Bright LED Lamps
Weight: 1.0g
Unit: mm
AND190HW
InGaN High Brightness White Light Emission
T-3 Package (10 mm)
Features
• New emission material (InGaN) white LED
• All plastic mold type, clear colorless lens
• Low drive current, (forward current = 1 to 20 mA)
• Excellent On-Off contrast ratio
• Fast response time, capable of pulse operation
• High power luminous intensity
• Suitable for Outdoor Message Signboards, Automotive use.
10.0±0.2
11.0±0.3
0.5
1.5 MIN.
27.0 MIN.
13.5 ± 0.3
2.0±0.2
Maximum Ratings (T
a
= 25°C)
Characteristics
Symbol
I
F
V
R
P
D
T
Opr
T
Stg
2.54
Cathode Index
Rating
30
5
108
-40 to 85
-40 to 85
Unit
mA
V
mW
°C
°C
Forward Current
Reverse Voltage
0.5
1 2
Power Dissipation
Operating Temperature Range
1. Anode
2. Cathode
Storage Temperature Range
Electro-Optical Characteristics (T
a
= 25°C)
Characteristics
Forward Voltage
Reverse Current
Luminous Intensity
Chromaticity Coordinates
Full Viewing Angle
Symbol
V
F
I
R
I
V
x
y
θ
Test Condition
I
F
= 20 mA
V
R
= 5 V
I
F
= 20 mA
I
F
= 10 mA
I
F
= 10 mA
I
V
= 1/2 Peak
Minimum
–
–
3,300
–
–
–
Typical
3.7
–
6,000
0.33
0.34
40
Maximum
4.3
10
–
–
–
–
Unit
V
µA
mcd
degree
Precaution
Please be careful of the following:
1. Soldering temperature: 260°C max
Soldering time: 5 sec. max
Soldering portion of lead: up to 1.6 mm from the body of the device
2. The lead can be formed up to 5 mm from the body of the device without forming stress.
Soldering should be performed after the lead forming.
3. Absolute secure counter measures against static electricity and surge should be taken when handling these
products. It is recommended to use wrist band or antistatic gloves when handling these LEDs.
Product specifications contained herein may be changed without prior notice.
It is therefore advisable to contact Purdy Electronics before proceeding with the design of equipment incorporating this product.
Purdy Electronics Corporation • 720 Palomar Avenue • Sunnyvale, CA 94085
Tel: 408.523.8200 • Fax: 408.733.1287 • email@purdyelectronics.com • www.purdyelectronics.com
4/4/05
AND190HW
InGaN High Brightness White Light Emission
Ultra Bright LED Lamps
I
F
– V
F
50000
50
30000
T
a
= 25°C
I
V
– I
F
Luminous Intensity I
V
(mcd)
3.2
3.4
3.6
3.8
4.0
4.2
Forward Current I
F
(mA)
30
T
a
= 25°C
10000
5000
3000
10
5
3
1000
500
0.5
1
2.8
3.0
1
3
5
10
30 50
100
Forward Voltage V
F
(V)
Forward Current I
F
(mA)
I
V
– T
C
3
1.0
Relative Luminous Intensity – Wavelength
I
F
= 20 mA
T
a
= 25°C
Relative Luminous Intensity
Relative Luminous Intensity
-20
0
20
40
60
80
0.8
1
0.5
0.3
0.6
0.4
0.2
0
400
0.1
500
600
Wavelength
λ
(nm)
700
800
Case Temperature T
C
(°C)
Radiation Pattern
40
10°
0°
Ta = 25°C
20°
30°
40°
50°
60°
70°
80°
90°
0
0.2
0.4
0.6
0.8
0
0
I
F
– T
a
20°
30°
40°
50°
60°
70°
80°
90°
10°
Allowable Forward Current I
F
(mA)
30
20
10
20
40
60
80
Ambient Temperature T
a
(°C)
100
Purdy Electronics Corporation • 720 Palomar Avenue • Sunnyvale, CA 94085
Tel: 408.523.8200 • Fax: 408.733.1287 • email@purdyelectronics.com • www.purdyelectronics.com
4/4/05
