AND520HG
Ultra Bright LED Lamps: Type 3
Weight: 0.31g
Unit: mm
AND520HG
5.9±0.3
GaN High Brightness Green Light Emission
• 5 mm (T1-3/4) Package
• Peak wavelength (lp = 540nm) high bright emission
• All plastic mold type, clear colorless lens
• Low drive current: 1 to 20 mA DC
• Excellent On-Off contrast ratio
• Fast response time, capable of pulse operation
• High power intensity – suitable for Outdoor Message Signboards
• High reliability
Maximum Ratings (T
a
= 25°C)
Characteristics
Forward Current
Reverse Voltage
Power Dissipation
Symbol
I
F
V
R
P
D
T
Opr
T
Sig
5.0±0.2
1.0±0.2
1.0 MAX.
26.4 MIN.
8.6±0.3
0.5
1.0 MIN.
Rating
30
5
120
-40 to 85
-40 to 100
Unit
mA
V
mW
C
C
2.54
Cathode Index
0.5
Operating Temperature Range
Storage Temperature Range
1
2
1. Anode
2. Cathode
Electro-Optical Characteristics (T
a
= 25°C)
Characteristics
Forward Voltage
Reverse Current
Luminous Intensity
Peak Emission Wavelength
Spectral Line Half Width
Dominant Wavelength
Full Viewing Angle
Symbol
V
F
I
R
I
V
l
P
∆l
ld
q
Test Condition
I
F
= 20 mA
V
R
= 5V
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
V
= 1/2 Peak
Minimum
–
–
2.500
–
–
–
–
Typical
3.5
–
5,000
525
35
530
20
Maximum
4.0
50
Unit
V
µA
mcd
–
–
–
–
nm
nm
nm
degree
Precaution
Please be careful of the following:
1. Soldering temperature: 260 C max.
Soldering time: 5 sec. max.
Soldering portion of lead: up to 1.6 mm from the body of the device
2. The lead can be formed up to 5 mm from the body of the device without forming stress.
Soldering should be performed after the lead forming.
3. Absolute secure counter measures against static electricity and surge should be taken when handling these products. It is
recommended to use wrist band or antistatic gloves when handling these LEDs.
Product specifications contained herein may be changed without prior notice.
It is therefore advisable to contact Purdy Electronics before proceeding with the design of equipment incorporating this product.
Purdy Electronics Corporation • 720 Palomar Avenue • Sunnyvale, CA 94085
Tel: 408.523.8200 • Fax: 408.733.1287 • email@purdyelectronics.com • www.purdyelectronics.com
4/4/05
AND520HG
GaN High Brightness Green Light Emission
I
F
– V
F
50
Luminous Intensity IV (mcd)
Ultra Bright LED Lamps: Type 3
IV – VF
Ta = 25°C
10000
5000
3000
Forward Current I
F
(mA)
30
T
a
= 25°C
10
5
3
1000
500
1
2.75
3..0
3.25
3.5
3.75
4.0
4.25
Forward Voltage V
F
(V)
200
1
3
5
10
30 50
100
300
Forward Current IF (mA)
I
V
– T
C
3
Relative Luminous Intensity
1.0
Relative Luminous Intensity – Wavelength
I
F
= 20 mA
T
a
= 25°C
Relative Luminous Intensity
0.8
1
0.5
0.3
0.6
0.4
0.2
0
500
525
550
575
600
Wavelength
λ
(nm)
0.1
-20
0
20
40
60
80
Case Temperature T
C
(°C)
Radiation Pattern
40
10°
0°
Ta = 25°C
20°
30°
40°
50°
60°
70°
80°
90°
0
0.2
0.4
0.6
0.8
0
0
Allowable Forward Current I
F
(mA)
I
F
– T
a
20°
30°
40°
50°
60°
70°
80°
90°
10°
30
20
10
20
40
60
80
Ambient Temperature T
a
(°C)
100
Purdy Electronics Corporation • 720 Palomar Avenue • Sunnyvale, CA 94085
Tel: 408.523.8200 • Fax: 408.733.1287 • email@purdyelectronics.com • www.purdyelectronics.com
4/4/05
