390217-4 Product Details
Live Product Chat
Memory Sockets
Always ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
No Im a ge Ava ila ble
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
390217-4
T E I nternal N umber: 3 9 0 2 1 7 - 4
Product Highlights:
l
Rambus RIMM
l
Gold (15) C ontact Mating Area Plating Material
l
Number of Positions = 184
l
DRAM Type = Direct RDRAM
l
DRAM Voltage = 2.5 V
View all Features
Obsolete
C ontact Product Information
C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
RIMM C ONNEC TOR 184 POSITION
(PDF, English)
Catalog Pages/Data Sheets:
l
PERSONAL SYSTEMS PRODUC TS
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
Rambus In-Line Memory Module (RIMM) Sockets
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Rambus RIMM
l
Number of Positions
= 184
l
DRAM Type
= Direct RDRAM
l
PC B Mount Style = Through Hole
l
Module Orientation
= Vertical
l
PC B Retention Feature = Yes
l
Profile = Standard
Mechanical Attachment:
l
C enter Retention Hole Diameter (mm [in])
= 2.44 [0.096]
Electrical Characteristics:
l
DRAM Voltage
= 2.5 V
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.79 [0.110]
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
C enterline (mm [in])
= 1.00 [0.039]
l
Number of Rows
= Dual
l
Ejector Type = Locking
l
Ejector Location
= Both Ends
l
Number of Bays
= 2
l
Number of Keys
= 2
l
PC B Retention Method = Boardlock(s)
l
Mount Type = Printed C ircuit Board
Contact Related Features:
l
C ontact Mating Area Plating Material = Gold (15)
l
C ontact Base Material = Phosphor Bronze
l
Retention Post Material = Stainless Steel
Housing Related Features:
l
Housing Material = High Temperature Nylon
l
Housing C olor = Black
l
Housing Flammability Rating = UL 94V-0
Configuration Related Features:
l
Insertion Style
= Direct Insert
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
l
RoHS/ELV C ompliance History = Always was ELV compliant
Operation/Application:
l
Application Type = RIMM, SPRIMM
Packaging Related Features:
l
Packaging Method = Tray
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
