5962-9461102HMX datasheet, PDF

Datasheet> All Categories > storage> storage> 5962-9461102HMX

5962-9461102HMX: DescriptionSRAM Module, 2MX8, 100ns, CMOS, CQMA68; Categorystorage storage; File Size266KB，6 Pages; ManufacturerMicrosemi; Websitehttps://www.microsemi.com

Download Datasheet Parametric Compare View All

5962-9461102HMX Overview

SRAM Module, 2MX8, 100ns, CMOS, CQMA68

5962-9461102HMX Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	QFP
package instruction	QFP,
Contacts	68
Reach Compliance Code	compliant
ECCN code	3A001.A.2.C
Maximum access time	100 ns
Other features	USER CONFIGURABLE AS 1M X 16 OR 2M X 8
JESD-30 code	S-CQFP-G68
JESD-609 code	e4
length	22.36 mm
memory density	16777216 bit
Memory IC Type	SRAM MODULE
memory width	32
Number of functions	1
Number of terminals	68
word count	524288 words
character code	512000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
organize	512KX32
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QFP
Package shape	SQUARE
Package form	FLATPACK
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Filter level	MIL-STD-883
Maximum seat height	4.57 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal surface	GOLD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	22.36 mm
Base Number Matches	1

Preview

Download Datasheet

View All

White Electronic Designs

512Kx32 SRAM MODULE, SMD 5962-94611

FEATURES

■

Access Times of 70, 85, 100, 120ns

Packaging

• 68 lead, Hermetic CQFP (G2T)

, 22.4mm (0.880

inch) square. 4.57mm (0.180 inch) high (Package

509)

■

Organized as 512Kx32, User Conﬁgurable as

1Mx16 or 2Mx8

Commercial, Industrial and Military Temperature

Ranges

TTL Compatible Inputs and Outputs

■

5V Power Supply

Low Power CMOS

WS512K32-XXX

Built-in Decoupling Caps and Multiple Ground Pins

for Low Noise Operation

Weight

• WS512K32-XG2TX

- 8 grams typical

Note 1: Package Not Recommended for New Designs.

This product is subject to change without notice.

FIGURE 1 – PIN CONFIGURATION FOR WS512K32-XG2TX

TOP VIEW

CS#

GND

CS#

WE#

PIN DESCRIPTION

I/O0-31

A0-18

WE#1-4

CS#1-4

OE#

GND

Data Inputs/Outputs

Address Inputs

Write Enables

Chip Selects

Output Enable

Power Supply

Ground

Not Connected

9 8 7 6 5 4 3 2 1 68 67 66 65 64 63 62 61

I/O

GND

I/O

27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43

I/O

GND

I/O

BLOCK DIAGRAM

W E #

CS#

OE#

0-18

W E #

CS#

W E #

CS#

W E #

CS#

OE#

CS#

WE#

512K x 8

I/O

0-7

I/O

8-15

I/O

16-23

I/O

24-31

Note 1: Package Not Recommended for New Designs.

March 2005

Rev. 4

White Electronic Designs Corporation • (602) 437-1520 • www.wedc.com

5962-9461102HMX Related Products

	5962-9461102HMX	5962-9461101HMX	5962-9461104HMX	5962-9461103HMX
Description	SRAM Module, 2MX8, 100ns, CMOS, CQMA68	SRAM Module, 2MX8, 120ns, CMOS, CQMA68	SRAM Module, 2MX8, 70ns, CMOS, CQMA68	SRAM Module, 2MX8, 85ns, CMOS, CQMA68
Is it lead-free?	Contains lead	Contains lead	Contains lead	Contains lead
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible
Parts packaging code	QFP	QFP	QFP	QFP
package instruction	QFP,	QFP,	QFP,	QFP,
Contacts	68	68	68	68
Reach Compliance Code	compliant	compliant	compliant	compliant
ECCN code	3A001.A.2.C	3A991.B.2.A	3A001.A.2.C	3A001.A.2.C
Maximum access time	100 ns	120 ns	70 ns	85 ns
Other features	USER CONFIGURABLE AS 1M X 16 OR 2M X 8	USER CONFIGURABLE AS 1M X 16 OR 2M X 8	USER CONFIGURABLE AS 1M X 16 OR 2M X 8	USER CONFIGURABLE AS 1M X 16 OR 2M X 8
JESD-30 code	S-CQFP-G68	S-CQFP-G68	S-CQFP-G68	S-CQFP-G68
JESD-609 code	e4	e4	e4	e4
length	22.36 mm	22.36 mm	22.36 mm	22.36 mm
memory density	16777216 bit	16777216 bit	16777216 bit	16777216 bit
Memory IC Type	SRAM MODULE	SRAM MODULE	SRAM MODULE	SRAM MODULE
memory width	32	32	32	32
Number of functions	1	1	1	1
Number of terminals	68	68	68	68
word count	524288 words	524288 words	524288 words	524288 words
character code	512000	512000	512000	512000
Operating mode	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C
organize	512KX32	512KX32	512KX32	512KX32
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QFP	QFP	QFP	QFP
Package shape	SQUARE	SQUARE	SQUARE	SQUARE
Package form	FLATPACK	FLATPACK	FLATPACK	FLATPACK
Parallel/Serial	PARALLEL	PARALLEL	PARALLEL	PARALLEL
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Filter level	MIL-STD-883	MIL-STD-883	MIL-STD-883	MIL-STD-883
Maximum seat height	4.57 mm	4.57 mm	4.57 mm	4.57 mm
Maximum supply voltage (Vsup)	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage (Vsup)	4.5 V	4.5 V	4.5 V	4.5 V
Nominal supply voltage (Vsup)	5 V	5 V	5 V	5 V
surface mount	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS
Temperature level	MILITARY	MILITARY	MILITARY	MILITARY
Terminal surface	GOLD	GOLD	GOLD	GOLD
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	1.27 mm	1.27 mm	1.27 mm	1.27 mm
Terminal location	QUAD	QUAD	QUAD	QUAD
width	22.36 mm	22.36 mm	22.36 mm	22.36 mm
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED
Maximum time at peak reflow temperature	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED
Base Number Matches	1	-	1	1
