Tri-State Enable/Disable 3.3V Oscillator
Model: H5C-2E3LF
RoHS Compliant / Pb Free
FEATURES
•
•
•
•
3.3V Operation
HCMOS Output
Tri-State Enable/Disable
8-Pin DIP
Rev. 9/18/2006
http://www.foxonline.com/need_a_sample.htm
OPTiOnS
• 14-Pin DIP Available (F5C-2E3LF)
learn more about:
Part Marking Identification
Mechanical Specification
internet required
• PART nUMbER SElEcTiOn
Learn More - Internet Required
Part Number
350LF-Freq-xxxxx
351LF-Freq-xxxxx
272LF-Freq-xxxxx
352LF-Freq-xxxxx
354LF-Freq-xxxxx
353LF-Freq-xxxxx
566LF-Freq-xxxxx
Model
Number
H5C-2E3LF
H5C-2E3RLF
H6C-2E3LF
H6C-2E3RLF
H7C-2E3LF
H7C-2E3RLF
H8C-2E3LF
Frequency
Operating
1
Stability Temperature (ºC)
±100PPM
0 ~ +70
±100PPM
-40 ~ +85
±50PPM
0 ~ +70
±50PPM
-40 ~ +85
±25PPM
0 ~ +70
±25PPM
-40 ~ +85
±20PPM
0 ~ +70
Frequency
Range (MHz)
1.000~160.000
1.000~160.000
1.000~160.000
1.000~160.000
1.000~160.000
1.000~125.000
1.000~125.000
• ElEcTRicAl cHARAcTERiSTicS
PARAMETERS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
1.000 ~ 23.999 MHz
24.000 ~ 49.999 MHz
50.000 ~ 69.999 MHz
70.000 ~ 125.000 MHz
125.000 ~ 160.000 MHz
Output Symmetry (50% V
dd
)
Rise Time (10% ~ 90% V
dd
) (T
r
)
Fall Time (90% ~ 10% V
dd
) (T
f
)
Output Voltage
(V
ol
)
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
(HCMOS)
Start-up Time
(T
s
)
Output Enable/Disable Time
2
1
MAX
(unless otherwise noted)
1.000 ~ 160.000 MHz
-55ºC ~ +125ºC
3.3V ± 10%
15mA
20mA
40mA
45mA
60mA
40% ~ 60%
10 nS
10 nS
10% V
dd
90% V
dd
Min
8mA Min
-8mA Min
15pF
10mS
100nS
All dimensions are in millimeters.
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration.
2
An internal pullup resistor from pin 1 to V
DD
allows active output if pin 1 is left open.
All specifications subject to change without notice.
• EnAblE / DiSAblE FUncTiOn
INH (Pin 1)
OUTPUT (Pin 5)
OPEN
2
ACTIVE
'1' Level V
ih
≥
2.2 V
ACTIVE
'0' Level V
il
≤
0.8 V
High Z
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
