5962-01-221-7185

Description

5962-01-221-7185 Amplifier basic information:

5962-01-221-7185 is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are DIP, DIP8,.3

5962-01-221-7185 amplifier core information:

The minimum operating temperature of 5962-01-221-7185 is 70 °C. Its maximum bias current at a peak reflow temperature of 22525°C is: 0.00015 µA

The manufacturer specifies a maximum slew rate of 0.8 mA and a minimum slew rate of 0.1 V/us for the 5962-01-221-7185. Its minimum voltage gain is 150000.

The power supply range is: +-2/+-20/4/40 V. The input offset voltage of 5962-01-221-7185 is 250 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the op amp 0V (or close to 0V).)

Related dimensions for 5962-01-221-7185:

5962-01-221-7185 has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 8

5962-01-221-7185 Amplifier Additional Information:

5962-01-221-7185 adopts the VOLTAGE-FEEDBACK architecture. It belongs to the low-bias class of amplifiers. It belongs to the low offset class of amplifiers. The frequency compensation status of 5962-01-221-7185 is: NO. Its temperature grade is: COMMERCIAL.

And its humidity sensitivity level is: 1. It is a micropower amplifier. 5962-01-221-7185 is not Rohs certified. It contains lead. The corresponding JESD-30 code is: R-PDIP-T8.

The encapsulation code of 5962-01-221-7185 is: DIP. 5962-01-221-7185 packaging materials are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. 5962-01-221-7185 package pin formats are: IN-LINE. Its terminal form is: THROUGH-HOLE.

CategoryAnalog mixed-signal IC    Amplifier circuit
File Size271KB,16 Pages
ManufacturerLinear ( ADI )
Websitehttp://www.analog.com/cn/index.html
Alternative parts:5962-01-221-7185
Download Datasheet Parametric View All

5962-01-221-7185 Overview

5962-01-221-7185 Amplifier basic information:

5962-01-221-7185 is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are DIP, DIP8,.3

5962-01-221-7185 amplifier core information:

The minimum operating temperature of 5962-01-221-7185 is 70 °C. Its maximum bias current at a peak reflow temperature of 22525°C is: 0.00015 µA

The manufacturer specifies a maximum slew rate of 0.8 mA and a minimum slew rate of 0.1 V/us for the 5962-01-221-7185. Its minimum voltage gain is 150000.

The power supply range is: +-2/+-20/4/40 V. The input offset voltage of 5962-01-221-7185 is 250 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the op amp 0V (or close to 0V).)

Related dimensions for 5962-01-221-7185:

5962-01-221-7185 has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 8

5962-01-221-7185 Amplifier Additional Information:

5962-01-221-7185 adopts the VOLTAGE-FEEDBACK architecture. It belongs to the low-bias class of amplifiers. It belongs to the low offset class of amplifiers. The frequency compensation status of 5962-01-221-7185 is: NO. Its temperature grade is: COMMERCIAL.

And its humidity sensitivity level is: 1. It is a micropower amplifier. 5962-01-221-7185 is not Rohs certified. It contains lead. The corresponding JESD-30 code is: R-PDIP-T8.

The encapsulation code of 5962-01-221-7185 is: DIP. 5962-01-221-7185 packaging materials are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. 5962-01-221-7185 package pin formats are: IN-LINE. Its terminal form is: THROUGH-HOLE.

5962-01-221-7185 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerLinear ( ADI )
Parts packaging codeDIP
package instructionDIP, DIP8,.3
Contacts8
Reach Compliance Codecompliant
ECCN codeEAR99
Amplifier typeOPERATIONAL AMPLIFIER
ArchitectureVOLTAGE-FEEDBACK
Maximum bias current (IIB) at 25C0.00015 µA
frequency compensationNO
Maximum input offset voltage250 µV
JESD-30 codeR-PDIP-T8
low-biasYES
low-dissonanceYES
micropowerYES
Humidity sensitivity level1
Number of functions1
Number of terminals8
Maximum operating temperature70 °C
Minimum operating temperature
Package body materialPLASTIC/EPOXY
encapsulated codeDIP
Encapsulate equivalent codeDIP8,.3
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)225
power supply+-2/+-20/4/40 V
Certification statusNot Qualified
minimum slew rate0.1 V/us
Maximum slew rate0.8 mA
Supply voltage upper limit20 V
surface mountNO
technologyBIPOLAR
Temperature levelCOMMERCIAL
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Minimum voltage gain150000
Base Number Matches1
LT1008
Picoamp Input Current,
Microvolt Offset,
Low Noise Op Amp
DESCRIPTIO
The LT
®
1008 is a universal precision operational amplifier
that can be used in practically all precision applications.
The LT1008 combines for the first time, picoampere bias
currents (which are maintained over the full – 55°C to
125°C temperature range), microvolt offset voltage (and
low drift with time and temperature), low voltage and
current noise, and low power dissipation. Extremely high
common mode and power supply rejection ratios, and the
ability to deliver 5mA load current with high voltage gain
round out the LT1008’s superb precision specifications.
The all around excellence of the LT1008 eliminates the
necessity of the time consuming error analysis procedure
of precision system design in many applications; the
LT1008 can be stocked as the universal precision op amp.
The LT1008 is externally compensated with a single ca-
pacitor for additional flexibility in shaping the frequency
response of the amplifier. It plugs into and upgrades all
standard LM108A/LM308A applications. For an internally
compensated version with even lower offset voltage but
otherwise similar performance see the LT1012.
, LT, LTC and LTM are registered trademarks of Linear Technology Corporation.
FEATURES
Guaranteed Bias Current
T
A
= 25°C: 100pA Max
T
A
= – 55°C to 125°C: 600pA Max
Guaranteed Offset Voltage: 120μV Max
Guaranteed Drift: 1.5μV/°C Max
Low Noise, 0.1Hz to 10Hz: 0.5μV
P-P
Guaranteed Low Supply Current: 600μA Max
Guaranteed CMRR: 114dB Min
Guaranteed PSRR: 114dB Min
Guaranteed Voltage Gain with 5mA Load Current
Available in 8-Lead PDIP and SO Packages
APPLICATIO S
Precision Instrumentation
Charge Integrators
Wide Dynamic Range Logarithmic Amplifiers
Light Meters
Low Frequency Active Filters
Standard Cell Buffers
Thermocouple Amplifiers
TYPICAL APPLICATIO
Input Amplifier for 4.5 Digit Voltmeter
100
Input Bias Current vs Temperature
1000pF
1
INPUT
0.1V
1V
9M
10V
900k
100V
90k
1000V
10k
FN507
ALLEN BRADLEY
DECADE VOLTAGE DIVIDER
100k
5%
15V
8
7
LT1008
6
9k*
0.1V
1V
10V
100V
1k*
1000V TO 1V FULL-SCALE
ANALOG-TO-DIGITAL
CONVERTER
INPUT BIAS CURRENT (pA)
50
UNDERCANCELLED UNIT
0
OVERCANCELLED UNIT
–50
+
3
2
4
–15V
–100
*RATIO MATCH
±0.01%
THIS APPLICATION REQUIRES LOW
BIAS CURRENT AND OFFSET VOLTAGE,
LOW NOISE AND LOW DRIFT WITH
TIME AND TEMPERATURE
1008 TA01
–150
–50 –25
U
U
U
50
25
0
75
TEMPERATURE (°C)
100
125
1008 TA02
1008fb
