Total-Space ACE
Data Sheet
Complete Rad Tolerant MIL-STD-1553 Solution
Model: BU-67521
Total-Space ACE is a completely integrated rad tolerant MIL-STD-1553 terminal in a single package, including
protocol, SRAM, dual transceivers and transformers, and is designed to interface to a host processor.
Applications
•
Launch Vehicles
•
Military Satellites
•
Research Satellites
•
International Space Station
•
Commercial Telecommunication Satellites
Need a Custom Solution?
DDC can customize designs for all
controllers, ranging from simple modifications of standard
products to fully customized solutions for commercial, military,
aerospace, and industrial applications.
For more information:
www.ddc-web.com/BU-67521
