(Note1) Pd deleted at 3.8mW/°C at temperatures above Ta=25°C.
Caution:
Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated over
the absolute maximum ratings.
Recommended Operating Range
Parameter
Power Supply Voltage
Operating Temperature Range
CR Timer Frequency Range
PWM Minimum Pulse Width
Symbol
V
IN
Topr
F
PWM
T
MIN
Rating
4.5 ~ 42
-40 ~ +125
1~10000
1
Unit
V
°C
Hz
µs
Recommended Operating Conditions
Parameter
Input Capacitor
CRT Terminal Capacitor
CRT Terminal Resistor
Symbol
C
IN
C
CRT
R
CRT
Min
0.1
19p
500
Limit
Typ
-
-
-
Max
-
18µ
5M
Unit
µF
F
Ω
Conditions
Ceramic capacitor recommended
Ceramic capacitor recommended
(Note2) The minimum value of capacitor must be met this specifications over full operating conditions. (ex. Temperature, DC bias, aging conditions)
(Note3) Set C
CRT
, R
CRT
to become desired frequency and Duty width by using equations shown in P.5.
Electrical Characteristics (Unless Otherwise Specified Ta=-40 to 125°C, V
