SPECIFICATION FOR APPROVAL
REF : 20080801-A
PROD.
NAME
PAGE: 1
ABC'S DWG NO.
ABC'S ITEM NO.
SH4022□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅰ﹒CONFIGURATION
& DIMENSIONS：
A
A
B
C
D
E
G
H
I
R
:
:
:
:
:
:
:
:
:
4.80±0.3
4.80±0.3
2.20±0.2
1.60 typ.
1.60 typ.
1.50 ref.
5.30 ref.
2.00 ref.
1.80 ref.
H
I
D
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
100
C
B
R
LCR Meter
c
E
D
( PCB Pattern suggestion )
Ⅱ﹒SCHEMATIC
DIAGRAM：
Ⅲ﹒MATERIALS：
a﹒Core：Ferrite DR core
a
b﹒Core：Ferrite RI core
c﹒Wire
：Enamelled
copper wire ( Class F & H)
d﹒Adhesive
：Epoxy
resin
Peak Temp：260℃ max.
Max. Peak Temp - 5℃：30sec max.
e﹒Terminal：Ag/Ni/Sn
Max time above 217℃
：60sec~150sec
max.
Temperature
f﹒Remark：Products comply with RoHS'
Rising Area
Preheat Area
requirements
+4.0
℃
/ sec max.
150 ~ 200
℃
/ 60 ~ 120sec
250
I
b
d
e
Reflow Area
+3.0
℃
/ sec max.
Forced Cooling Area
-(1.0 ~ 5.0)
℃
/ sec max.
Peak Temperature:
260℃
217℃
Temperature (
℃
)
Ⅳ﹒GENERAL
SPECIFICATION：
a﹒Temp. rise
：20℃
typ.
b﹒Storage temp.：-40℃ ----+125℃
c﹒Operating temp.：-40℃----+105℃
d﹒Resistance to solder heat：260℃.10 secs.
200
150
60sec~120sec
60sec max.
100
50
0
50
100
150
Time ( seconds )
G
60sec~150sec
200
250
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20080801-A
PROD.
NAME
PAGE: 2
ABC'S DWG NO.
ABC'S ITEM NO.
SH4022□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅴ﹒
ELECTRICAL CHARACTERISTICS：
Inductance
(
μH
)
1.5
±30％
2.2
±30％
3.3
±30％
4.7
±30％
6.8
±30％
10.0
±30％
15.0
±30％
22.0
±30％
33.0
±30％
47.0
±30％
68.0
±30％
100.0
±30％
120.0
±30％
150.0
±30％
Q
ref.
8.0
8.0
8.0
8.0
9.0
9.0
22.0
15.0
15.0
13.0
13.0
20.0
30.0
40.0
Test Freq.
(MHz)
7.960
7.960
7.960
7.960
7.960
2.520
2.520
2.520
2.520
2.520
2.520
0.796
0.796
0.796
SRF
(MHz)
typ.
100.0
70.0
60.0
50.0
35.0
30.0
20.0
18.0
15.0
12.0
11.0
9.0
9.0
8.0
RDC
(mΩ)
max.
typ.
13.5
16.5
24.0
37.0
50.0
65.0
98.0
138.0
217.0
269.0
409.0
513.0
585.0
738.0
20.0
25.0
36.0
55.0
70.0
85.0
130.0
180.0
280.0
350.0
520.0
650.0
730.0
930.0
Irms
(mA)
typ.
3500
3300
3000
2200
2000
1700
1300
1100
800
700
600
550
520
450
Isat
(mA)
typ.
1800
1600
1400
1100
950
800
680
530
420
350
300
240
210
180
DWG No.
SH40221R5YL□ -□□□
SH40222R2YL□ -□□□
SH40223R3YL□ -□□□
SH40224R7YL□ -□□□
SH40226R8YL□ -□□□
SH4022100YL□ -□□□
SH4022150YL□ -□□□
SH4022220YL□ -□□□
SH4022330YL□ -□□□
SH4022470YL□ -□□□
SH4022680YL□ -□□□
SH4022101YL□ -□□□
SH4022121YL□ -□□□
SH4022151YL□ -□□□
1).
2)."-
":Reference code
3). Inductance Test Freq.
：100KHz
/0.1V
4). Irms base on Temp. rise 20
℃
typ.
5). Isat base on
△L/L0A＝35％
typ.
□□□
：Packaging
Information… A：Bulk B：Taping Reel
@ Inductance VS. DC Currrent Curve
2
10 2
7
5
101
Inductance（uH）
470
3
2
10 1
7
5
3
2
10 0
7
5
10 1
2
1R5
100
4R7
3
5 7 10 2
2
3
5 7 10 3
2
3
5 7 10 4
DC Current (mA)
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20080801-A
PROD.
NAME
PAGE: 3
ABC'S DWG NO.
ABC'S ITEM NO.
SH4022□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅵ﹒PACKAGING
INFORMATION：
( 1 ) Configuration
T
Cover tape
2.0±0.5
A
B
∮
C
∮
C
N
G
D
Embossed carrier
※
Carrier tape width : D
P:8 m/m
End
4 m/m
Start
100
100
100
100
Leadr
no component
200 m/m min.
Components
User direction of feed
Trailer
no component
400 m/m min.
( 2 ) Dimensions
Style
07 - 12
A
178
B
21±0.8
C
13
D
12
G
14
+0
N
50
-0
Unit:m/m
T
16.5
( 3 ) Q'TY & G.W. Per package
Inner : Reel
Series
SH4022
Q'TY (pcs)
G.W. (gw)
Style
Q'TY (pcs)
Outer : Carton
G.W. (Kg)
Size (cm)
800
135
07 - 12
32,000
8.20
42 x 41 x 24
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20080801-A
PROD.
NAME
PAGE: 4
ABC'S DWG NO.
ABC'S ITEM NO.
SH4022□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅶ﹒DWGING
NUMBER EXPRESSION：
S
H
4
0
2
2
Reference code
Appendix code 2 : Package
Appendix code 1 : Classification
Tolerance code
Electrical code
Dimension code
Type code
Appendix code 1：Product Classification
L：Lead Free Standard products comply with RoHS' requirements
1 ~ 9：Lead Free Special products comply with RoHS' requirements
Appendix code 2：Package Information
Code
A
B
T.B.D.
T / R ( Reel package )
Inner package
Inner package Q'TY
T.B.D.
800
pcs
Remark
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20080801-A
PROD.
NAME
PAGE: 5
ABC'S DWG NO.
ABC'S ITEM NO.
SH4022□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅷ﹒RELIABILITY
TEST：
Test item
Specification
Test condition
Preheat : 155
℃
/ 4 hours.
Solder : Sn96.5 / Ag3 / Cu0.5 or equivalent
Solder temp. : 235±5℃
Flux : Rosin
Dip time : 5±0.5 seconds
Solderability
More than 95% of the
terminal electrode
Shall be covered
With fresh solder.
Thermal shock test
( Temp. cycle )
Electrical oharacteristics shall
not change more
than
±20%
Room temp.
15 minutes
Room temp.
15 minutes
Total : 50 cycles
-40
℃
30 minutes
+105
℃
30 minutes
Humidity test
Temperature : 40±2℃
Humidity : 90±5%
Time : 1000 hours
High temp.
Resistance test
Temperature : 105±5℃
Applied current : Per spec.
Time : 96 hours
AR-001A
