HEF4029BPN datasheet, PDF - EEWORLD Datasheet

HEF4029BPN: DescriptionIC 4000/14000/40000 SERIES, SYN POSITIVE EDGE TRIGGERED 4-BIT BIDIRECTIONAL BINARY COUNTER, PDIP16, PLASTIC, SOT-38-1, DIP-16, Counter; Categorylogic logic; File Size185KB，14 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric View All

HEF4029BPN Overview

IC 4000/14000/40000 SERIES, SYN POSITIVE EDGE TRIGGERED 4-BIT BIDIRECTIONAL BINARY COUNTER, PDIP16, PLASTIC, SOT-38-1, DIP-16, Counter

Parameter Name	Attribute value
Maker	NXP
Parts packaging code	DIP
package instruction	PLASTIC, SOT-38-1, DIP-16
Contacts	16
Reach Compliance Code	unknown
Other features	BINARY/BCD COUNT OPTION; TCO OUTPUT; COUNT ENABLE INPUT
Counting direction	BIDIRECTIONAL
series	4000/14000/40000
JESD-30 code	R-PDIP-T16
length	21.6 mm
Load/preset input	YES
Logic integrated circuit type	BINARY COUNTER
Operating mode	SYNCHRONOUS
Number of digits	4
Number of functions	1
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
propagation delay (tpd)	290 ns
Certification status	Not Qualified
Maximum seat height	4.7 mm
Maximum supply voltage (Vsup)	15 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Trigger type	POSITIVE EDGE
width	7.62 mm
minfmax	8 MHz
Base Number Matches	1

INTEGRATED CIRCUITS

DATA SHEET

For a complete data sheet, please also download:

•

The IC04 LOCMOS HE4000B Logic

Family Specifications HEF, HEC

•

The IC04 LOCMOS HE4000B Logic

Package Outlines/Information HEF, HEC

HEF4029B

MSI

Synchronous up/down counter,

binary/decade counter

Product speciﬁcation

File under Integrated Circuits, IC04

January 1995
