3-188442-1 Product Details
Live Product Chat
Product View
Standard Board Mount Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3-188442-1
T E I nternal N umber: 3 - 1 8 8 4 4 2 - 1
Product Highlights:
l
Number of Positions = 25
l
Plug
l
PC B Mount Angle = Vertical
l
Product Series = HDP-20
l
With Mating C onnector Lock
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Number of Positions
= 25
l
Gender
= Plug
l
PC B Mount Angle
= Vertical
l
Product Series
= HDP-20
l
Mating C onnector Lock
= With
l
Mating C onnector Lock Type
= Female Screwlocks, 4-40 UNC
l
PC B Retention Feature
= Yes
l
Shell Type
= Full Metal
l
Shell Size
= 3
l
PC B Thickness (in [mm])
= 0.197 [5.00]
l
Grounding Indents
= Without
l
Grounding Straps
= Without
l
PC B Mount Style
= Through Hole
l
C olor C ode
= None
l
Sealed = No
l
C olor = Black
l
Shell Material = Steel
Mechanical Attachment:
l
Panel Attachment
= Without
l
Female Screwlock Material = Steel
l
Female Screwlock Plating = Tin
Termination Related Features:
l
Grounding C lips
= Without
l
Termination Post Length (mm [in])
= 5.80 [0.228]
l
Solder Tail C ontact Plating
= Bright Tin-Lead
Body Related Features:
l
PC B Retention Method
= AC TION PIN (C ompliant) Posts
l
Shell Plating = Tin
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (50)
l
C ontact Base Material = Phosphor Bronze
l
Approved Standards = DIN 41652
l
Performance Level = Level 1
Housing Related Features:
l
Housing Material = Polyester GF
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Operation/Application:
l
Application = Standard
Other:
l
Brand = AMP
