DS55110AJ/883 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> DS55110AJ/883

DS55110AJ/883: DescriptionLine Driver, 1 Func, 2 Driver, BIPolar, CDIP14, CERAMIC, DIP-14; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size807KB，6 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

DS55110AJ/883 Overview

Line Driver, 1 Func, 2 Driver, BIPolar, CDIP14, CERAMIC, DIP-14

DS55110AJ/883 Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	CERAMIC, DIP-14
Contacts	14
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	ADDITIONAL COMMON ENABLE INPUT
Differential output	YES
Number of drives	2
Input properties	GATED
Interface integrated circuit type	LINE DRIVER
Interface standards	GENERAL PURPOSE
JESD-30 code	R-GDIP-T14
length	19.43 mm
Nominal negative supply voltage	-5 V
Number of functions	1
Number of terminals	14
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
Maximum seat height	5.08 mm
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	NO
technology	BIPOLAR
Temperature level	MILITARY
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
maximum transmission delay	15 ns
width	7.62 mm
Base Number Matches	1
