Bulletin PD-2.306 rev. I 04/05
31DQ09
31DQ10
SCHOTTKY RECTIFIER
3.3 Amp
Major Ratings and Characteristics
Characteristics
I
F(AV)
Rectangular
waveform
V
RRM
I
FSM
@ tp = 5 µs sine
V
F
T
J
@ 3 Apk, T
J
= 25°C
Description/ Features
Units
A
V
A
V
°C
The 31DQ.. axial leaded Schottky rectifier has been opti-
mized for very low forward voltage drop, with moderate
leakage. Typical applications are in switching power sup-
plies, converters, free-wheeling diodes, and reverse
battery protection.
Low profile, axial leaded outline
High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
Very low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term
reliability
Lead-Free plating
Values
3.3
90/100
210
0.85
- 40 to 150
CASE STYLE AND DIMENSIONS
Outline C - 16
Dimensions in millimeters and inches
www.irf.com
1
31DQ09, 31DQ10
Bulletin PD-2.306 rev. I 04/05
Voltage Ratings
Part number
V
R
Max. DC Reverse Voltage (V)
V
RWM
Max. Working Peak Reverse Voltage (V)
31DQ09
90
31DQ10
100
Absolute Maximum Ratings
Parameters
I
F(AV)
Max. Average Forward Current
* See Fig. 4
I
FSM
E
AS
I
AR
Max. Peak One Cycle Non-Repetitive
Surge Current * See Fig. 6
Non-Repetitive Avalanche Energy
Repetitive Avalanche Current
210
34
3.0
0.5
A
mJ
A
Following any rated
load condition and with
10ms Sine or 6ms Rect. pulse rated V
RRM
applied
T
J
= 25 °C, I
AS
= 1.0 Amps, L = 6 mH
Current decaying linearly to zero in 1 µsec
Frequency limited by T
J
max. V
A
= 1.5 x V
R
typical
5µs Sine or 3µs Rect. pulse
31DQ..
3.3
Units
A
Conditions
50% duty cycle @ T
L
= 108°C, rectangular wave form
Electrical Specifications
Parameters
V
FM
Max. Forward Voltage Drop
* See Fig. 1
(1)
31DQ.. Units
0.85
0.97
0.69
0.80
V
V
V
V
mA
mA
pF
nH
V/µs
@ 3A
@ 6A
@ 3A
@ 6A
Conditions
T
J
= 25 °C
T
J
= 125 °C
V
R
= rated V
R
I
RM
C
T
L
S
Max. Reverse Leakage Current
* See Fig. 2
Typical Series Inductance
(1)
Typical Junction Capacitance
1
3
110
9.0
10000
T
J
= 25 °C
T
J
= 125 °C
V
R
= 5V
DC
(test signal range 100Khz to 1Mhz) 25°C
Measured lead to lead 5mm from package body
(Rated V
R
)
dv/dt Max. Voltage Rate of Change
(1) Pulse Width < 300µs, Duty Cycle <2%
Thermal-Mechanical Specifications
Parameters
T
J
T
stg
Max. Junction Temperature Range
Max. Storage Temperature Range
31DQ.. Units
-40 to 150
-40 to 150
80
15
°C
°C
Conditions
R
thJA
Max. Thermal Resistance Junction
to Ambient
R
thJL
Typical Thermal Resistance Junction
to Lead
wt
Approximate Weight
Case Style
°C/W DC operation
Without cooling fins
°C/W DC operation
1.2 (0.042) g (oz.)
C - 16
2
www.irf.com
31DQ09, 31DQ10
Bulletin PD-2.306 rev. I 04/05
10
T J = 150˚C
10
Reverse Current - I
R
(mA)
1
0.1
0.01
0.001
25˚C
125˚C
0.0001
0
0
20
40
60
80
100
Reverse Voltage - V
R
(V)
Instantaneous Forward Current - I
F
(A)
T
J
= 150˚C
1
Fig. 2 - Typical Values Of Reverse Current
Vs. Reverse Voltage
T
J
= 125˚C
T
J
= 25˚C
1000
Junction Capacitance - C
T
(pF)
T = 25˚C
J
100
0.1
0
0.3
0.6
0.9
1.2
Forward Voltage Drop - V
FM
(V)
Fig. 1 - Max. Forward Voltage Drop Characteristics
10
0
40
80
120
160
Reverse Voltage - V
R
(V)
Fig. 3 - Typical Junction Capacitance
Vs. Reverse Voltage
www.irf.com
3
31DQ09, 31DQ10
Bulletin PD-2.306 rev. I 04/05
160
Allowable Lead Temperature (°C)
4
Average Power Loss (Watts)
D = 0.20
D = 0.25
D = 0.33
D = 0.50
D = 0.75
DC
RMS Limit
140
120
100
Square wave (D = 0.50)
80% Rated Vr applied
3
DC
2
1
80
see note (2)
60
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5
Average Forward Current - I
F(AV)
(A)
Fig. 4 - Max. Allowable Lead Temperature
Vs. Average Forward Current
0
0
1
2
3
4
5
Average Forward Current - I
F(AV)
(A)
Fig. 5- Forward Power Loss
Characteristics
Non-Repetitive Surge Current - I
FSM
(A)
1000
At Any Rated Load Condition
And With Rated VRRM Applied
Following Surge
100
10
10
100
1000
10000
Square Wave Pulse Duration - t
p
(microsec)
Fig. 6 - Max. Non-Repetitive Surge Current
(2)
Formula used: T
C
= T
J
- (Pd + Pd
REV
) x R
thJL
;
Pd = Forward Power Loss = I
F(AV)
x V
FM
@ (I
F(AV)
/
D) (see Fig. 6);
Pd
REV
= Inverse Power Loss = V
R1
x I
R
(1 - D); I
R
@ V
R1
= 80% rated V
R
4
www.irf.com
31DQ09, 31DQ10
Bulletin PD-2.306 rev. I 04/05
Ordering Information Table
Device Code
31
1
1
2
3
4
5
-
-
-
-
-
D
2
Q
3
10
4
TR
5
31 = 3.3A (Axial and small packages - Current is x10)
D = DO-201 package
Q = Schottky Q.. Series
10 = Voltage Ratings
TR
= Tape & Reel package (1200 pcs)
none = Box package (500 pcs)
10 = 100V
09 = 90V
31DQ10
********************************************
* SPICE Model Diode
*
********************************************
.SUBCKT 31DQ10 ANO CAT
D1 ANO 1 CAT
*Define diode model
.MODEL DMOD D(Is=56.46E-06 N=2.202 Rs=28.27E-03 Ikf=0.5957 Xti=2 Eg=1.11
+
Cjo=199.3E-12 M=0.4572 Vj=1.873 Fc=0.5 Isr=165.6E-24 Nr=4.955
+
Bv=119.9 Ibv=215.5E-06 Tt=21.64E-09)
********************************************
.ENDS 31DQ10
Data and specifications subject to change without notice.
This product has been designed and qualified for Industrial Level and Lead-Free.
Qualification Standards can be found on IR's Web site.
IR WORLD HEADQUARTERS:
233 Kansas St., El Segundo, California 90245, USA Tel: (310) 252-7105
TAC Fax: (310) 252-7309
Visit us at www.irf.com for sales contact information. 04/05
www.irf.com
5
