3051/1VI001 Overview

Wire And Cable,

3051/1VI001 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Alpha Wire
Reach Compliance Code	compliant
Connector bracket type	WIRE AND CABLE
Base Number Matches	1

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. 3051/1

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

1 X 1 HOOKUP

22 (SOLID) AWG TC

0.016" Wall, Nom. PVC

0.025

0.057+/- 0.002

ALPHA WIRE E163869-* RU AWM STYLES 1569 105C

OR 1007 80C VW-1 300V 22 AWG ---- LXXXX CSA

(1) Print

TR-64 90C FT1 ROHS

{0} * = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN

ORANGE, SLATE, VIOLET

(2) Color(s)

Applicable Specifications

1) UL

AWM/STYLE 1007

AWM/STYLE 1569

VW-1

2) CSA International

TR-64

FT1

90°C

80°C / 300 VRMS

105°C / 300 VRMS

Environmental

1) EU Directive 2011/65/EU(RoHS2):

All materials used in the manufacture of this part are in compliance with European Directive

2011/65/EU regarding the restriction of use of certain hazardous substances in electrical and

electronic equipment. Consult Alpha Wire's web site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

3) California Proposition 65:

The outer surface materials used in the manufacture of this part meet the requirements of

California Proposition 65.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

Electrical Properties

1) Voltage Rating

2) Inductance

3) Conductor DCR

-40 to 105°C

10X Cable Diameter

5 Lbs, Maximum

(For Engineering purposes only)

300 VRMS

0.07 µH/ft, Nominal

16.9 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 1000 FT

b) 100 FT

Flange x Traverse x Barrel (inches)

6.5 x 2 x 1.9 Continuous length

2.75 x 2 x 1.125 Continuous length

[Spool dimensions may vary slightly]

Notes:

a) Certain colors and put-up combinations may only be available by special order, minimums may apply.

www.alphawire.com

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742)

Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure their accuracy at the time of publication, information and specifications

described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not

ensure product availability.

Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or

implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,

even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out

of or in connection with the use, or inability to use, the information or specifications described herein.

ALPHA WIRE - CONFIDENTIAL AND PROPRIETARY

Notice to persons receiving this document and/or technical information. This document is confidential and is the exclusive property of ALPHA WIRE,

and is merely on loan and subject to recall by ALPHA WIRE at any time. By taking possession of this document, the recipient acknowledges and

agrees that this document cannot be used in any manner adverse to the interests of ALPHA WIRE, and that no portion of this document may be

copied or otherwise reproduced without the prior written consent of ALPHA WIRE. In the case of conflicting contractual provisions, this notice shall
