BAW56E6327HTSA1

Description
Rectifier Diode, 2 Element, 0.2A, 80V V(RRM), Silicon, SOT-23, 3 PIN
CategoryDiscrete semiconductor    diode
File Size149KB,12 Pages
ManufacturerInfineon
Websitehttp://www.infineon.com/
Environmental Compliance
Download Datasheet Parametric View All

BAW56E6327HTSA1 Overview

Rectifier Diode, 2 Element, 0.2A, 80V V(RRM), Silicon, SOT-23, 3 PIN

BAW56E6327HTSA1 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?conform to
MakerInfineon
Parts packaging codeSOT-23
package instructionR-PDSO-G3
Contacts3
Reach Compliance Codecompliant
ECCN codeEAR99
ConfigurationCOMMON ANODE, 2 ELEMENTS
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
JESD-30 codeR-PDSO-G3
JESD-609 codee3
Humidity sensitivity level1
Number of components2
Number of terminals3
Maximum output current0.2 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Maximum power dissipation0.33 W
Certification statusNot Qualified
Maximum repetitive peak reverse voltage80 V
Maximum reverse recovery time0.004 µs
surface mountYES
Terminal surfaceTin (Sn)
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Base Number Matches1
BAW56...
Silicon Switching Diode
For high-speed switching applications
Common anode configuration
BAW56S / U: For orientation in reel see
package information below
Pb-free (RoHS compliant) package
1)
Qualified according AEC Q101
BAW56
BAW56W
!
BAW56S
BAW56U
$
#
, "
"
, !
,
,
,
,


!
Type
BAW56
BAW56S
BAW56U
BAW56W
1
Pb-containing
Package
SOT23
SOT363
SC74
SOT323
Configuration
common anode
double common anode
double common anode
common anode
Marking
A1s
A1s
A1s
A1s
package may be available upon special request
1
2007-09-19
