repeatability, compatibility, and easy installation
and maintenance
•
Removable adapters for easy cleaning
•
Industry’s highest packaging density (up to 32
modules per chassis)
•
Occupies one half-depth slot for most modules
(two half-depth slots for 1x16 module)
PRODUCT OVERVIEW
ARRIS OP3xSx family of splitters and combiners have been designed with high uniformity, low insertion loss, and polarization
dependent loss. The product family of modules includes 1x4, 2x4, 1x8, and 1x16 splitters/combiners; dual 1x2, 1x3, and 2x2
splitters/combiners; and a family of dual 1x2 splitters/combiners having unbalanced outputs with split ratios ranging from 55/45 to
99/1. A unique scalable 8x8 splitter/combiner is also available from ARRIS and described in a separate data sheet. All modules utilize
SC/APC type connectors that can be removed for easy cleaning.
Ask us about the complete Access Technologies Solutions portfolio:
ISP-OP3xSx
Fiber-Deep
DOCSIS
®
3.1
Node Segmentation
HPON
™
/RFoG
FTTx
OP3xSx
ARRIS’ single mode, multiband splitters and combiners are packaged in ARRIS’s very compact half-depth module for mounting in
the CH3000 chassis. The packaging concept for ARRIS’s family of optical passives is similar to the well-recognized LGX package;
and, although ARRIS’s version of the LGX module is slightly narrower (for higher packaging density), it will also mount in any
standard LGX chassis. ARRIS’s implementation maintains the advantages of the LGX concept (which enables easy, snap-in
installation) while providing higher packaging density, greater flexibility and scalability to the network operator.
SPECIFICATIONS
Characteristics
Physical
Dimensions
Weight
Environmental
Operating temperature range (indoor)
Storage temperature range
Humidity
Optical Interface
Optical connectors
Optical
Operating wavelength
Directivity
Return loss, min
Input power handling, min
SC/APC
1263.5-1357.5 nm and 1423.5-1655 nm for 1x2, 1x3, 1x4, 2x2, and 2x4
1263.5-1655.0 nm for 1x8 and 1x16
55 dB
55 dB
> 30 dBm
Specification
6.5” D x 4.3” H x 1.0” W (3RU) (17 cm x 11 cm x 2.5 cm)
0.8 lbs (0.34 kg)
–20° to +65°C (–4° to +149°F)
–40° to +85°C (–40° to +185°F)
5% to 95% non-condensing
TABLE 1: INSERTION LOSS
Part Number
OP31S2D-EQ-00-AS
OP31S3D-EQ-00-AS
OP32S2D-EQ-00-AS
OP31S4S-EQ-00-AS
OP32S4S-EQ-00-AS
OP31S8S-EQ-00-AS
OP31S16S-EQ-00-AS
OP31S2D-55-00-AS
OP31S2D-60-00-AS
OP31S2D-65-00-AS
OP31S2D-70-00-AS
OP31S2D-75-00-AS
OP31S2D-80-00-AS
OP31S2D-85-00-AS
OP31S2D-90-00-AS
OP31S2D-95-00-AS
OP31S2D-99-00-AS
Package Design
Dual 1x2
Dual 1x3
Dual 2x2
1x4
2x4
1x8
1x16
Dual 1x2
Dual 1x2
Dual 1x2
Dual 1x2
Dual 1x2
Dual 1x2
Dual 1x2
Dual 1x2
Dual 1x2
Dual 1x2
Split Ratio [%]
50/50
33/33/33
50/50
4 x 25%
4 x 25%
8 x 12%
16 x 6%
55/45
60/40
65/35
70/30
75/25
80/20
85/15
90/10
95/5
99/1
Insertion Loss [dB],
typical (max)
3.5 (3.9)
5.1 (5.5)
3.5 (3.9)
6.7 (7.2)
6.7 (7.2)
10.2 (10.7)
13.4 (13.9)
3.2 (3.3)/3.8 (4.2)
2.7 (3.1)/4.3 (4.9)
2.4 (2.8)/4.9 (5.5)
2.0 (2.4)/5.6 (6.1)
1.7 (2.1)/6.4 (6.9)
1.5 (1.9)/7.3 (7.9)
1.2 (1.4)/8.4 (9.1)
1.0 (1.2)/10.3 (10.9)
0.6 (0.9)/13.2 (14.0)
0.2 (0.6)/19.7 (20.0)
Uniformity [dB],
typical (max)
0.5 (0.7)
0.5 (0.8)
0.5 (0.7)
0.5 (0.8)
0.5 (0.8)
0.7 (1.0)
0.8 (1.1)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Ask us about the complete Access Technologies Solutions portfolio:
ISP-OP3xSx
Fiber-Deep
DOCSIS
®
3.1
Node Segmentation
HPON
™
/RFoG
FTTx
OP3xSx
ORDERING INFORMATION
O
P
3
*
S
*
*
–
*
*
–
0
0
–
A
S
Optical Passive Module
Number of Inputs per Splitter/Combiner (1 or 2)
Splitter (Combiner)
Number of Outputs per Splitter/Combiner
1
(2, 3, 4, 8, or 16)
Splitter Packages per Module (S = Single, D = Dual)
Split Ratio
2
Growth Fields (code “00” when ordering)
AS = SC/APC Connector
NOTES:
1. Not all combinations of numbers of inputs and outputs are valid. Reference above table for available combinations.
2. Specify split ratio for higher percentage value of two unbalanced outputs (55, 60, . . ., 95 or 99). Encode “EQ” for models with balanced outputs. Split ratios are identical for
modules with dual splitter packages.
RELATED PRODUCTS
CH3000 chassis
LGX chassis
Optical Patch Cords
Optical Passives
Note:
Specifications are subject to change without notice.
